Features:
wireless signals systems
special communication systems
Features:
high gain and good looking
light weight and low VSWR
Specification:
Fiberglass omni antennas TQJ-1500C
Category |
Fiberglass Antennas |
Model |
TQJ-1500C |
Frequency Range-MHz |
1400~1550 |
Bandwidth-MHz |
40 |
Gain-dBi |
10 |
Vertical Beamwidth-° |
16 |
VSWR |
≤1.5 |
Nominal Impedance-Ω |
50 |
Polarization |
Vertical |
Maximum Power-W |
100 |
Dimension-m |
1.2 |
Weight-kg |
1 |
Rated Wind Velocity-m/s |
60 |
Connector |
N Female or Customization |
Mounting Mast Diameter-mm |
Φ40~50 |
Omni antenna
Omnidirectional antennas,the performance is 360 ° uniform radiation in the horizontal direction ,
which is usually referred to a nonoriented.Under normal circumstances the width of the lobe is smaller, the larger the gain.Omnidirectional antenna general used in a communication system from the past, a large coverage area, cheap.
