Cat.6 A FTP Toolless Keystone Jack
1.CAT 6A &CAT6 FTP TOOLLESS180° Keystne jack
2.Shielded Housing:ZINC ALLOY
3.Plastic Housing:UL94-VO
4.IDC Material:UL94-VO
5.Termination:Phosphor Bronze,Tin Plated
6.8PINS:Gold Plating 3U"-50u"
7.RJ45 Contacts:≥750 Times
8.IDN life:≥250 Times
9.Compliant with EIA/TIA specifications
10.Dual color-coded label for both T568A/T568B wiring schemes
Environmental
1.Storage:-40℃~+70℃
2.Operation:-10℃~+60℃
3.ROHS COMPLIANT
Strip approximately 40mm the cable jacket,fold back the foil and the braid shield
Follow the label color on the modular cover,set each wire into proper position,ensure the ground wire connect properly
Set the modular cover to the module,and cut the wire with scissors to flat
Finish the assembly by hand,and cut the excrescent wires
Finished products
