Specifications
DSTP-42 Concrete Pumps1.SWEDISH SSAB steel plates
2.GERANY HBC remote-control device,SIEMENS electric components
DSTP-42 Concrete Pumps
1. Max. pumping height: 41.8m
2. Pumping system: Adopt steel plates all from SWEDISH SSAB, Original GERMANY STEIBEL transfer case and REXROTH pump/valve group
3. Bucket: Big-capacity collecting bucket affords no dead angle and easy cleaning
4. Control system: Adopt original GERANY HBC wireless remote-control device and SIEMENS electric components
Main technical parameters of DSTP-42 Concrete Pumps
In working condition:
Transport capacity in theory-------------------------------------------------125m3/h
Pumping capacity index-------------------------------------------------------586MPa.*m3/h
Max. concrete pressure-------------------------------------------------------8.5MPa
Bucket volume-------------------------------------------------------------------620L
Bucket top surface height from the ground-------------------------------1400mm
Distribution valve form---------------------------------------------------------“S” valve
Max. pumping radius-----------------------------------------------------------38m
Max. pumping height-----------------------------------------------------------41.8m
Max. pumping depth------------------------------------------------------------28m
Delivery pipe’s diameter-------------------------------------------------------Φ125mm
Tail hose’s length----------------------------------------------------------------3m
Pumping pipe’s rotary range--------------------------------------------------365°
Boom’s section number--------------------------------------------------------4
In driving condition:
Max. speed-----------------------------------------------------------------------85km/h
Min. turning radius-------------------------------------------------------------10200mm
Brake distance------------------------------------------------------------------10m
Approach angle-----------------------------------------------------------------24°
Departure angle-----------------------------------------------------------------15°
Truck chassis brand------------------------------------------------------------SINO/ISUZU
Engine max. output power----------------------------------------------------286kw (1800r/min)
Engine max. output torque---------------------------------------------------1422N.m (1080r/min)
Fuel consumption limit---------------------------------------------------------40L/100km
Full-load weight------------------------------------------------------------------35000kg
Outline dimension---------------------------------------------------------------13650x2490x3960mm
(Parameter is changed without prior notice.)
