DSTP-48 truck mounted boom concrete pump dealer
- 10 Unit / Units per Month
- Qingdao
- T/T
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | DASION |
Model Number: | DSTP-48 |
Product Description
Specifications
DSTP-48 Truck-mounted Concrete Pump1.SWEDISH SSAB steel plates
2.GERANY HBC remote-control device,SIEMENS electric components
DSTP-48 truck-mounted Concrete Pump
1. Max. pumping height: 47.7m
2. Pumping system: Adopt steel plates all from SWEDISH SSAB, Original GERMANY STEIBEL transfer case and REXROTH pump/valve group
3. Bucket: Big-capacity collecting bucket affords no dead angle and easy cleaning
4. Control system: Adopt original GERANY HBC wireless remote-control device and SIEMENS electric components
Main technical parameters of DSTP-48 Concrete Pump
In working condition:
Transport capacity in theory--------------------------------------------------125m3/h
Pumping capacity index--------------------------------------------------------586MPa.*m3/h
Max. concrete pressure--------------------------------------------------------8.5MPa
Bucket volume-------------------------------------------------------------------620L
Bucket top surface height from the ground--------------------------------1400mm
Distribution valve form---------------------------------------------------------“S” valve
Max. pumping radius-----------------------------------------------------------43.7m
Max. pumping height-----------------------------------------------------------47.7m
Max. pumping depth------------------------------------------------------------34.3m
Delivery pipe’s diameter-------------------------------------------------------Φ125mm
Tail hose’s length---------------------------------------------------------------3m
Pumping pipe’s rotary range--------------------------------------------------365°
Boom’s section number--------------------------------------------------------5
In driving condition:
Max. speed-----------------------------------------------------------------------80km/h
Min. turning radius-------------------------------------------------------------11000mm
Brake distance------------------------------------------------------------------10m
Approach angle-----------------------------------------------------------------25°
Departure angle-----------------------------------------------------------------10°
Truck chassis brand------------------------------------------------------------SINO/ISUZU
Engine max. output power----------------------------------------------------273kw (1800r/min)
Engine max. output torque---------------------------------------------------1460N.m (1080r/min)
Fuel consumption limit---------------------------------------------------------40L/100km
Full-load weight------------------------------------------------------------------40000kg
Outline dimension---------------------------------------------------------------13300x2500x4000mm
(Parameter is changed without prior notice.)
