Specifications
DSTP-45 Concrete Pump Cars1.SWEDISH SSAB steel plates
2.GERANY HBC remote-control device,SIEMENS electric components
DSTP-45 Concrete Pump Cars
1. Max. pumping height: 44.7m
2. Pumping system: Adopt steel plates all from SWEDISH SSAB, Original GERMANY STEIBEL transfer case and REXROTH pump/valve group
3. Bucket: Big-capacity collecting bucket affords no dead angle and easy cleaning
4. Control system: Adopt original GERANY HBC wireless remote-control device and SIEMENS electric components
Main technical parameters of DSTP-45 Concrete Pump Cars
In working condition:
Transport capacity in theory-------------------------------------------------125m3/h
Pumping capacity index-------------------------------------------------------586MPa.*m3/h
Max. concrete pressure-------------------------------------------------------8.5MPa
Bucket volume-------------------------------------------------------------------620L
Bucket top surface height from the ground-------------------------------1400mm
Distribution valve form---------------------------------------------------------“S” valve
Max. pumping radius-----------------------------------------------------------40.7m
Max. pumping height-----------------------------------------------------------44.7m
Max. pumping depth------------------------------------------------------------31.3m
Delivery pipe’s diameter-------------------------------------------------------Φ125mm
Tail hose’s length----------------------------------------------------------------3m
Pumping pipe’s rotary range--------------------------------------------------365°
Boom’s section number---------------------------------------------------------5
In driving condition:
Max. speed-----------------------------------------------------------------------85km/h
Min. turning radius-------------------------------------------------------------11900mm
Brake distance------------------------------------------------------------------10m
Approach angle-----------------------------------------------------------------25°
Departure angle-----------------------------------------------------------------10°
Truck chassis brand------------------------------------------------------------SINO/ISUZU
Engine max. output power----------------------------------------------------287kw (1800r/min)
Engine max. output torque---------------------------------------------------1863N.m (1080r/min)
Fuel consumption limit---------------------------------------------------------40L/100km
Full-load weight-----------------------------------------------------------------38000kg
Outline dimension--------------------------------------------------------------13100x2500x3900mm
(Parameter is changed without prior notice.)
