T Bar Forming Machine

Name: T Bar Forming Machine
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 15 Set / Sets per Month
Port Shanghai or Ningbo
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

T Bar Forming Machine

1. Machine components:

Roll forming machine consists of uncoiler, coil sheet guiding device, main roll forming system, cutting device, Hydraulic station, PLC control system and support table.

2. Technical Parameters:

Item		Specification
Material	Type	Pre-painted steel coil & galvanized coils
	Thickness	0.3-0.7mm
	Yield strength	235-345Mpa
Roller material		45#Chrome steel
Forming speed		About 20m/min
Output speed		10m/min
Speed adjusting mode		AC Frequency
Roller drive		Decelerating motor + Chain drive
Cutting mode		Hydraulic cutting
Cutter material		Cr12 mould steel
Length measurement		Encoder
Control mode		Mitsubishi PLC
Operating mode		Button + Mitsubishi Touch screen
Main motor power		4KW
Hydraulic station motor power		2.2 KW

*Welcome to our factory

* Welcome inquiry us. We are sure you good machine quality and good service after sales.
