cement brick making machine DS8-15 full-automatic concrete block making machine price in india price
DS8-15 full-automatic buring-free paving block Making Machine:
1. Compatible with fixed standard brick, hollow block, brick and other concrete products;
2. Mandatory feeder to insure uniformity of material and consistent product strength;
3. Adopt full program adopt PLC control and intelligent man-machine interface dialogue system;
4. Reasonable distribution of vibration to increase the effect of vibrating speed.
DS8-15 full-automatic buring-free paving block Making Machine:
Mandatory feeder: once fabric box arrives to the top of the mold box, the mixing fork starts stirring rapidly to insure uniformity of material, and insure consistent product strength.
2. Full program adopt PLC control and intelligent man-machine interface dialogue system: easy to achieve a random signal analysis, fault diagnosis and a variety of parameter settings to ensure the best effectiveness of the block machine.
3. Increase the effective work platform: the application of new vibration technologies makes our block machines work with a larger platform, which greatly raised the production efficiency.
4. Reasonable distribution of vibration: the adoption of the fuel tank will release mold box locked in vibration mode platform, equipped with special vibrator on pressure head to achieve the mold box and platform vibrating at same time, to increase the effect of vibrating speed. The rapid vibration make the concrete rapid-liquefaction and rapid-exhaust, to achieve the finish products high-density and high-strength.
Main technical parameters of DS8-15 full-automatic buring-free paving block making machine:
Parameter Name |
Parameter values |
||
The largest machine dimensions |
7200×2100×2825(L×W×H)(mm) |
||
Rated pressure of hydraulic system |
21Mpa |
||
Main vibration form |
All vibration molded desk |
||
Vibration frequency |
50~70Hz |
||
Vibration acceleration |
10-15g |
||
To adapt to the high brick |
50-200mm |
||
Pallet size |
Bamboo |
920×850×40(mm) |
|
Molding cycle |
15s |
||
Machine power |
36.8kw |
||
Machine weight |
11.8t |
||
Our DS8-15 full-automatic buring-free paving block making machine picture with mould:
The DS8-15 full-automatic buring-free paving block making machine and the brick type:
The DS8-15 full-automatic buring-free paving block making machine operation schematic diagram:
The customer visit our factory:
The hollow blocks and paving blocks samples:
Some kinds of moulds:
We sent the multi-function full-automatic blcok production line to our customer:
