Specifications
hollow block making machine philippines:1.ISO9001:2008 & CE
2.multi-purpose design
3.Adopt full program
4.PLC
hollow block making machine philippines DS8-15 automatic concrete brick block making machine suppliers
DS8-15 Block Making Machinery:
1.Mandatory feeder: once fabric box arrives to the top of the mold box, the mixing fork starts stirring rapidly to insure uniformity of material, and insure consistent product strength.
2. Full program adopt PLC control and intelligent man-machine interface dialogue system: easy to achieve a random signal analysis, fault diagnosis and a variety of parameter settings to ensure the best effectiveness of the block machine.
3. Increase the effective work platform: the application of new vibration technologies makes our block machines work with a larger platform, which greatly raised the production efficiency.
4. Reasonable distribution of vibration: the adoption of the fuel tank will release mold box locked in vibration mode platform, equipped with special vibrator on pressure head to achieve the mold box and platform vibrating at same time, to increase the effect of vibrating speed. The rapid vibration make the concrete rapid-liquefaction and rapid-exhaust, to achieve the finish products high-density and high-strength.
Main technical parameters of DS8-15 block making machinery:
Parameter Name |
Parameter values |
||
The largest machine dimensions |
7200×2100×2825(L×W×H)(mm) |
||
Rated pressure of hydraulic system |
21Mpa |
||
Main vibration form |
All vibration molded desk |
||
Vibration frequency |
50~70Hz |
||
Vibration acceleration |
10-15g |
||
To adapt to the high brick |
50-200mm |
||
Pallet size |
Bamboo |
920×850×40(mm) |
|
Molding cycle |
15s |
||
Machine power |
36.8kw |
||
Machine weight |
11.8t |
||
Main product specifications and production of each plate:
Model |
Block Specifications (mm) |
Forming a number of |
Molding cycle |
Capacity (pcs) |
|
DS8-15 |
390×190×190 (brick) |
8 |
15 |
15360 |
|
240×115×90 (brick) |
21 |
15 |
40320 |
||
240×115×53 (standard brick) |
42 |
15 |
80640 |
||
This series of 150-650 tons of products with different specifications. Brick shaped mold can be produced according to user needs. | |||||
Production conditions: | |||
Production sites |
Venues |
10-15acres |
|
Operate camp |
60 |
||
Raw space |
300 |
||
Office space |
30 |
||
Other conditions |
Staff |
10-15people |
|
Distribution |
40kw |
||
Water |
10T/day |
||
Model |
Block Specifications(mm) |
Forming Number (brick) |
Molding Cycle (seconds) |
Capacity (pcs) (8 hours) |
DS4-35 |
390 × 190 × 190 (hollow brick) |
4 |
35-40 |
3000-3290 |
240 × 115 × 90 (porous brick) |
9 |
35-40 |
7000-7400 |
|
240 × 115 × 53 (standard brick) |
21 |
35-40 |
15000-17200 |
|
|
Bamboo pallet size: 920 × 570 × 20mm Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm Total weight: 4.5T |
||||
DS4-15 |
390 × 190 × 190 (hollow brick) |
4 |
20-25 |
4608-5760 |
240 × 115 × 90 (porous brick) |
13 |
20-25 |
14950-18720 |
|
240 × 115 × 53 (standard brick) |
26 |
20-25 |
29900-37440 |
|
|
Bamboo pallet size: 920 × 570 × 20mm Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm Total weight: 8.5T |
||||
DS6-15 |
390 × 190 × 190 (hollow brick) |
6 |
15-25 |
7000-11520 |
240 × 115 × 90 (porous brick) |
12 |
15-25 |
14000-23040 |
|
240 × 115 × 53 (standard brick) |
30 |
15-25 |
34560-57600 |
|
Bamboo pallet size: 800 × 700 × 25mm Host power: 29.7KW |
||||
Machine size: 8800 × 1600 × 2750(L×W×H)mm Total weight: 10.5T |
||||
DS8-15 |
390 × 190 × 190 (hollow brick) |
8 |
15-20 |
11520-15360 |
240 × 115 × 90 (porous brick) |
21 |
15-20 |
30240-40320 |
|
240 × 115 × 53 (standard brick) |
42 |
15-20 |
60480-80640 |
|
|
Bamboo pallet size: 920 × 850 × 40mm Host power: 36.8KW Machine size: 7200 × 2100 × 2825(L×W×H)mm Total weight: 11.8T |
||||
DS10-15 |
390 × 190 × 190 (hollow brick) |
10 |
15-20 |
14400-19200 |
240 × 115 × 90 (porous brick) |
24 |
15-20 |
34560-46080 |
|
240 × 115 × 53 (standard brick) |
51 |
15-20 |
73440-97920 |
|
|
Bamboo pallet size: 1070 × 840 × 40mm Host power: 36.8KW Machine size: 7200 × 2290 × 3100(L×W×H)mm Total weight: 14.8T |
||||
