2015 K-62 250w Series Industrial Power Supply ac dc Switching 12v 20a 24v 10a Power Supply With Fan and CE UL GS

2015 K-62 250w Series Industrial Power Supply ac dc Switching 12v 20a 24v 10a Power Supply With Fan and CE UL GS thumbnail-1
2015 K-62 250w Series Industrial Power Supply ac dc Switching 12v 20a 24v 10a Power Supply With Fan and CE UL GS photo-1
US$ 1 - 100 MOQ: 500 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K-szpower
Model Number:
K-62
Contact Supplier Request Quote Chat Now
Shenzhen You Guan Yuan Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen&Hongkong&Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K-szpower
Model Number K-62
Output Power Other, 200wmax
Output Type Single
Input Voltage Other, 85-264VAC, 85-264VAC
Output Voltage 3.3v ~48v
Output Frequency 50/60HZ
Output Current 22.5A ~60A
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS


250W Single Output Switching Power Supply (M Series)

Low cost,high reliability
Built-in EMI filter
Low output ripple&noise
Protections:Over load/Short circuit
1 year warranty
Case:823 Size:199×99×50mm
AC input voltage range-----------88-132VAC/ 176-264VAC selected by switch
Input frequency---------------------------------47-63Hz
AC inrush current--------------------------------Cold start,40A/230VAC
DC adjustment range-----------------------------±10% rated output voltage
Line regulation(full load)------------------------≤0.5%
Output over load protection-------110%-150% hiccup mode,auto-recovery
Rise,hold up time--------------------50mS,20mS at full load(typical)
Withstand voltage-------I/P-O/P,I/P-FG:1.5KVAC, O/P-FG: 0.5KVAC, 1min
Working temperature----- -10~+40℃@100%,+60℃@60% load
Storage temperature----- -20℃~+85℃,20%~95%RH(non condensing)
Safety standards------Design refer to GB4943,UL60950-1,EN60950-1
EMC standards------- Design refer to GB9254,EN55022 class A
Cooling method---------------------Forced air cooling by Built-in DC fan

Product model

DC output

Load regul.

R&N

Efficiency

k-250M-3.3

3.3V,60A

2%

100mV

73%

K-250M -5

5V,50A

2%

100mV

78%

K-250M-7.5

7.5V,40A

1%

100mV

78%

K-250M-12

12V,22.5A

1%

120mV

80%



2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
 2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
2015 K-62 250w series industrial power supply ac dc switching 12v 20a 24v 10a power supply with fan and CE UL GS
