Help CenterRD-8099 QR Code 2d Handheld Barcode Scanner
US$ 1 - 150
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
CMOS
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RD-8099 2D Handheld Laser Barcode ScannerUS$ 1 - 125MOQ: 1 Piece -
NEW Arrival ! RD-1200 - USB Interface Type Laser Scan Element Type 2D Barcode Scanner For 1D /2D/QR Code /PDF417/MaxiCodes/US$ 1 - 99MOQ: 1 Piece
-
RD-8099 Wired 2D qr Code Barcode Scanner 2d Coms Barcode Scanner 2d Barcode ScannerNegotiableMOQ: 1 Piece
-
RD-8099 Wired 2d Barcode Generator 2d Bar Code qr Code Reader 2d Bar Code ReaderNegotiableMOQ: 1 Piece
-
RD-8099 Wired 2d Barcode Scanner Fingerprint Reader 2d Barcode Scanner Handheld 2d Barcode Scanner COMSNegotiableMOQ: 1 Piece
Products Status
Stock
Type
Barcode Scanner
Scan Element Type
CMOS
Colour Depth
32 Bit
Interface Type
COM, PS/2, USB
Max Paper Size
N/a
Optical Resolution
0.01mm
Scan Speed
Second
Brand Name
RADALL
Model Number
RD-8099
Place of Origin
Guangdong, China
Product Description
RD-8099 QR code 2d handheld wired barcode scanner
| 1 | Physical Characteristics | ||
| 1.1 | Dimensions: | 51mm x 30.61mm(width) x 21mm(height) | |
| 1.2 | Weight: | ||
| 1.3 | Voltage and Current: | 5 +/-10%VDC @ 350 mA | |
| 1.4 | Item name | QR barcode scanner | |
| 2 | Performance Characteristics | ||
| 2.1 | Light Source: | Aiming: 528 nm LED; illumination: 630 nm LED | |
| 2.2 | Field of View: | 34° V x 46° H(Vertical x Horizontal) | |
| 2.3 | Roll / Pitch / Yaw: | 360°, ±65°, ±60° | |
| 2.4 | Scan Performance: |
|
|
| 3 | Symbology Decode Capability | ||
| 3.1 | 1-D: | UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32 | |
| 3.2 | PDF417 (and Variants): | PDF417, microPDF417 and composite codes | |
| 3.3 | Postal: | U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch | |
| 3.4 | 2-D: | MaxiCode, DataMatrix (ECC 200), and QR barcode scanner | |
| 3.5 | Print Contrast: | 25% minimum reflectance | |
| 3.6 | Motion Tolerances: | Horizontal velocity: 5 in. (12.7 cm) per second | |
| 3.7 | Interfaces Supported: | IE1100: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces. | |
| 4 | Imaging Characteristics | ||
| 4.1 | Image (Pixels): | 0.35 Megapixel 752 pixels H x 480 pixels V | |
| 4.2 | Graphics Format Support: | Images can be exported as Bitmap, Jpeg, and Tiff | |
| 4.3 | Image Transfer Speed: | USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rate | |
| 4.4 | Image Transfer Time: | Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kb | |
| 5 | User Environment | ||
| 5.1 | Operating Temperature: | 32° to 122° F / 0° to 50° C | |
| 5.2 | Storage Temperature: | -40° to 158° F / -40° to 70° C | |
| 5.3 | Humidity: | 5% to 95%, non-condensing | |
| 5.4 | Drop/Shock Specifications: | Withstands 2000g to concrete | |
| 5.5 | Ambient Light Immunity: | Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. |
|
Advantage:
- Super decoding ability
- Decoding rate: 200 times per second
- Customer setting: Barcode setting mode, easy to operate
- Full independent intellectual property right
- Intelligent AGC control
- Antiknock, full quakeproof design, withstand 2m drops
- Comfortable button, service life of button up to 5million times
- Support 20 countries keyboard language
