RD-8099 Wired 2D qr Code Barcode Scanner 2d Coms Barcode Scanner 2d Barcode Scanner
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
Other, COMS barcode scanner
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RD-8099 Wired 2d Barcode Generator 2d Bar Code qr Code Reader 2d Bar Code ReaderNegotiableMOQ: 1 Piece -
RD-8099 Wired 2d Barcode Scanner Fingerprint Reader 2d Barcode Scanner Handheld 2d Barcode Scanner COMSNegotiableMOQ: 1 Piece
-
RD-8099 Handheld Wired QR Code Scanner With USB InterfaceUS$ 1 - 129MOQ: 1 Piece
-
RD-8099 QR Code 2d Handheld Barcode ScannerUS$ 1 - 150MOQ: 1 Piece
-
RD-8099 2D Handheld Laser Barcode ScannerUS$ 1 - 125MOQ: 1 Piece
Products Status
Stock
Type
Barcode Scanner
Scan Element Type
Other, COMS barcode scanner
Colour Depth
32 Bit
Interface Type
PS/2, USB, Other, PS/2, USB, RS232
Max Paper Size
A4
Optical Resolution
0.01mm
Scan Speed
200 times/sec
Brand Name
RADALL
Model Number
RD-8099
Place of Origin
Guangdong, China
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
Trade Assurance
Product Description
Specification :
parameters
| 1 | Physical Characteristics | ||
| 1.1 | Dimensions: | 51mm x 30.61mm(width) x 21mm(height) | |
| 1.2 | Weight: | ||
| 1.3 | Voltage and Current: | 5 +/-10%VDC @ 350 mA | |
| 1.4 | Item name | QR barcode scanner | |
| 2 | Performance Characteristics | ||
| 2.1 | Light Source: | Aiming: 528 nm LED; illumination: 630 nm LED | |
| 2.2 | Field of View: | 34° V x 46° H(Vertical x Horizontal) | |
| 2.3 | Roll / Pitch / Yaw: | 360°, ±65°, ±60° | |
| 2.4 | Scan Performance: |
|
|
| 3 | Symbology Decode Capability | ||
| 3.1 | 1-D: | UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32 | |
| 3.2 | PDF417 (and Variants): | PDF417, microPDF417 and composite codes | |
| 3.3 | Postal: | U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch | |
| 3.4 | 2-D: | MaxiCode, DataMatrix (ECC 200), and QR barcode scanner | |
| 3.5 | Print Contrast: | 25% minimum reflectance | |
| 3.6 | Motion Tolerances: | Horizontal velocity: 5 in. (12.7 cm) per second | |
| 3.7 | Interfaces Supported: | IE1100: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces. | |
| 4 | Imaging Characteristics | ||
| 4.1 | Image (Pixels): | 0.35 Megapixel 752 pixels H x 480 pixels V | |
| 4.2 | Graphics Format Support: | Images can be exported as Bitmap, Jpeg, and Tiff | |
| 4.3 | Image Transfer Speed: | USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rate | |
| 4.4 | Image Transfer Time: | Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kb | |
| 5 | User Environment | ||
| 5.1 | Operating Temperature: | 32° to 122° F / 0° to 50° C | |
| 5.2 | Storage Temperature: | -40° to 158° F / -40° to 70° C | |
| 5.3 | Humidity: | 5% to 95%, non-condensing | |
| 5.4 | Drop/Shock Specifications: | Withstands 2000g to concrete | |
| 5.5 | Ambient Light Immunity: | Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. |
|
Advantage:
- Super decoding ability
- Decoding rate: 200 times per second
- Customer setting: Barcode setting mode, easy to operate
- Full independent intellectual property right
- Intelligent AGC control
- Antiknock, full quakeproof design, withstand 2m drops
- Comfortable button, service life of button up to 5million times
- Support 20 countries keyboard language
Packing List
Wireless barcode scanner: 1PC
User Guide: 1PC
USB Cable: 1PC
Why Choose RADALL?
1. Factory direct sale, lowest price
2. Unique design, very comfortable operation sense.
3. Scan depth of field up to 800mm.
4. Full quakeproof, waterproof, dustproof, antiknock-design and EMI Shielding; Suitable with each kind of industrial environment.
5. Error rate less than 1/8 million.
6. Service life of button reaches up to 5 million times.
7. Full independent intellectual property rights.
