RD-8099 Wired 2d barcode generator 2d bar code qr code reader 2d bar code reader
Trade Assurance
Specification :
parameters
| 1 | Physical Characteristics | ||
| 1.1 | Dimensions: | 51mm x 30.61mm(width) x 21mm(height) | |
| 1.2 | Weight: | ||
| 1.3 | Voltage and Current: | 5 +/-10%VDC @ 350 mA | |
| 1.4 | Item name | QR barcode scanner | |
| 2 | Performance Characteristics | ||
| 2.1 | Light Source: | Aiming: 528 nm LED; illumination: 630 nm LED | |
| 2.2 | Field of View: | 34° V x 46° H(Vertical x Horizontal) | |
| 2.3 | Roll / Pitch / Yaw: | 360°, ±65°, ±60° | |
| 2.4 | Scan Performance: |
|
|
| 3 | Symbology Decode Capability | ||
| 3.1 | 1-D: | UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32 | |
| 3.2 | PDF417 (and Variants): | PDF417, microPDF417 and composite codes | |
| 3.3 | Postal: | U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch | |
| 3.4 | 2-D: | MaxiCode, DataMatrix (ECC 200), and QR barcode scanner | |
| 3.5 | Print Contrast: | 25% minimum reflectance | |
| 3.6 | Motion Tolerances: | Horizontal velocity: 5 in. (12.7 cm) per second | |
| 3.7 | Interfaces Supported: | IE1100: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces. | |
| 4 | Imaging Characteristics | ||
| 4.1 | Image (Pixels): | 0.35 Megapixel 752 pixels H x 480 pixels V | |
| 4.2 | Graphics Format Support: | Images can be exported as Bitmap, Jpeg, and Tiff | |
| 4.3 | Image Transfer Speed: | USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rate | |
| 4.4 | Image Transfer Time: | Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kb | |
| 5 | User Environment | ||
| 5.1 | Operating Temperature: | 32° to 122° F / 0° to 50° C | |
| 5.2 | Storage Temperature: | -40° to 158° F / -40° to 70° C | |
| 5.3 | Humidity: | 5% to 95%, non-condensing | |
| 5.4 | Drop/Shock Specifications: | Withstands 2000g to concrete | |
| 5.5 | Ambient Light Immunity: | Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. |
|
Advantage:
- Super decoding ability
- Decoding rate: 200 times per second
- Customer setting: Barcode setting mode, easy to operate
- Full independent intellectual property right
- Intelligent AGC control
- Antiknock, full quakeproof design, withstand 2m drops
- Comfortable button, service life of button up to 5million times
- Support 20 countries keyboard language
| Product Overviews |
- Comerical POS system(supermarket,store,shop,mall)
- Warehousing andlodistics
- Libraries
- Banks and Telecom
- Transportation
- Postal service
- Industrial and manufacturing management
| Packaging & Shipping |
Packing List
Wireless barcode scanner: 1PC
User Guide: 1PC
USB Cable: 1PC
Hello, my friend!!! Welcome to Radall, if you have any question, please feel free to contact us. We will try our best to solve your problems.
Contact details:
Grace Zeng:
TM: cn1513277261
Skype: live:radall001
Cola Yang:
TM: cn1513245115
Skype: live:radall002
Yoyo Ye:
TM: cn1513247549
Skype:live:radall003
Shipping:
We are the manufactures which support the Trade Assurance. The shipping service of Alibaba can protect the customers receive the goods safely!!!
Payment Ways:
Producing Flow
All products are manufactured in the factory under International Standards Organization (ISO) conditions. To ensure the highest product quality and consistency, every single product, rather than random samples, has been strictly tested before shipped. Radall maintains an ongoing program of three times testing and approval in order to ensure that its products meet the highest standards for performance integrity.
Certicifications:
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
RD-8099 Wired 2D qr code barcode scanner 2d coms barcode scanner 2d barcode scanner
