Specifications
50 tons SINO 6*4 wrecker truck1. OEM & Customized
2. 3C & ISO approved
3. Best quality and reasonable price
50 tons SINO 6*4 wrecker truck
According to structural specralgy of the device, it can be divided into four types, they are the separating type, the unit size, back loading type and go up and down type. The separating type is hang arm and triailing arm can work without each other. The unit hangs the arm and trailing arm to bind for an organic whole to hold and hang the size of uniting.The back loading type is through towed to hang. The going up and down type moves transmitting and overhead manipulation throught hoisting and lower the platform.
Chassis |
Brand |
SINOTRUCK |
||
Chassis model |
ZZ1256M4646C |
|||
Drive model |
6×4 |
|||
Tire |
11.00-20 |
|||
Brake |
Air brake |
|||
Engine |
Model |
WD615.97E |
||
Horse Power |
300 |
|||
Displacement(ml)/Power(kw) |
9726/221 |
|||
Emission |
Euro Ⅲ |
|||
|
Main Parameter |
Overall dimension (MM) |
L*W*H |
9500*2496*3250 |
|
wheelbase |
4325+1350, |
|||
Axles No. |
3 |
|||
Weight(KG) |
GVW |
25000 |
||
Payload weight |
/ |
|||
Curb weight |
18870 |
|||
Leaf spring No. |
9/12 |
|||
Approaching/Departure Angle(°) |
15/9 |
|||
Front/Rear trace(mm) |
1939 /1800 |
|||
Front/Rear suspension(mm) |
1560/2265 |
|||
Max speed(km/h) |
80 |
|||
Gear box |
9 speed |
|||
Front/Rear Axle Load |
7T/13T |
|||
Special Specification |
Rated hoisting weight(T) |
5~10 |
||
Bracket arm extension route(mm) |
1000 |
|||
Bracket arm Max. effctive length(mm) |
2300 |
|||
Max. lifting weight(T) (optional) |
16 |
|||
Max. lifting height(mm) (optional) |
4500 |
|||
Hoisting arm telescope length (mm) (optional) |
3100 |
|||
Max. traction speed(km/h) |
50 |
|||
winch |
Winch quantity(unit) |
2 |
||
Max. traction weight(T) |
20 |
|||
Rope Length(m) |
40 |
|||
Rope speed(m/min) |
8 |
|||
Support leg(optional) |
Quantity(unit) |
2 |
||
Support leg span(mm) |
800 |
|||
The Lufeng company has been granted the Quality System Certificate in conformity with ISO 9001:2000 and has passed China Compulsory Certification. The Lufeng brand products have more than 200 varieties of five series including semi-trailer, tank truck, wrecker, auto-unloading vehicle and highway maintenance vehicle. We can design and produce special purpose vehicles and special type vehicles according to different requirements of customers. Our products sell well in domestic market and have been sold to more than 20 countries of worldwide.
The above information is just for your reference. We can manufacture the trucks as per your request.
And wo We also produce other kinds of Special truck:
1. water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3. Fire engine truck
4. Truck mounted crane, crane truck
5. Dump truck, tipper, heavy duty truck
6. LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck, garbage compactor truck, sealed garbage truck
9. Fecal suction truck, sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck, insulated truck, refrigeration truck
13. Semi Trailer, Low plate semi-trailer, oil semi-trailer, van semi-trailer, bulk cement transportation semi-trailer, container semi-trailer, chemical liquid semitrailer, etc more than 300 types in total.
