Flate road wrecker truck
- 500 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card
- Multifunction platform wrecker body wrecker bed towing equipment tow truck accessories parts
- Shacman X3000 10*6 460hp 50ton 60ton wrecker truck for sale
- 40 ton heavy duty wrecker tow trucks for sale 50 ton rotator boom crane wrecker truck
- Shacman F3000 8x4 12 wheel 30ton rotator rescue wrecker truck
- howo 6x4 wrecker truck 20ton 25ton heavy duty tow and lift truck wrecker
- 16 ton wrecker China IVECO technology GENLYON Hongyan 4x2 tow truck
Product Details
Fuel Type: | Diesel | Emission Standard: | Euro 3 | Condition: | New |
Transmission Type: | Automatic | Dimensions (L x W x H) (mm): | 7240*2300*2360 | Place of Origin: | Hubei, China |
Brand Name: | dongfeng | Model Number: | EQ1070TJ9AD3 |
Product Description
Specifications
Flate road wrecker truck1. Good quality
2. Wonderful appeaence
3. warm service
EQ1070TJ9AD3 4*2 road wrecker truck
dongfeng duolika EQ1070TJ9AD3 4*2 road wrecker truck
dongfeng duolika 3 tons to 5 tons 4*2 road wrecker truck
Flate road wrecker truck
According to structural specralgy of the device, it can be divided into four types, they are the separating type, the unit size, back loading type and go up and down type. The separating type is hang arm and triailing arm can work without each other. The unit hangs the arm and trailing arm to bind for an organic whole to hold and hang the size of uniting.The back loading type is through towed to hang. The going up and down type moves transmitting and overhead manipulation throught hoisting and lower the platform.
Chassis Model /Brand |
EQ1070TJ9AD3 EQ1070/Dongfeng | ||||
Overall Dimension | Length×Width×Height | mm | 7240×2300×2360 | ||
Total Mass |
Kg
| 7000 | |||
Kerb Weight |
| 4600 | |||
Engine | Model/ Rated Power Emission standard | CY4102 96KW/130hp Euro3 | |||
driving type | 4*2 | ||||
Type & Size of Tyre | 7.50-16 | ||||
Wheel Base | mm | 3815 | |||
Approach/departure angle | ° | 23/11 | |||
Front/Rear suspension | mm | 1015/2410 | |||
Number of leaf spring of suspension | piece | 8/6+5 | |||
Front/Rear track | mm | 1504/1425 | |||
Max Speed | Km/h | 95 | |||
Material | Carbon steel | ||||
special system | Max lifting capacity: 2.25ton | ||||
| Max lifting pull capacity: 3-4tons
|
1 Important parts are made from high strength steel HG70.
2 The hydraulic system adopts two stage filtering technology, ensuring cleaning of the hydraulic system.
3 Hydraulic line key sealing using the Germanic sealing.
4 Five kinds lifting forks, and two kinds Lifting Fork Holder with
The Lufeng company has been granted the Quality System Certificate in conformity with ISO 9001:2000 and has passed China Compulsory Certification. The Lufeng brand products have more than 200 varieties of five series including semi-trailer, tank truck, wrecker, auto-unloading vehicle and highway maintenance vehicle. We can design and produce special purpose vehicles and special type vehicles according to different requirements of customers. Our products sell well in domestic market and have been sold to more than 20 countries of worldwide.
The above information is just for your reference. We can manufacture the trucks as per your request.
And wo We also produce other kinds of Special truck:
1. water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3. Fire engine truck
4. Truck mounted crane, crane truck
5. Dump truck, tipper, heavy duty truck
6. LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck, garbage compactor truck, sealed garbage truck
9. Fecal suction truck, sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck, insulated truck, refrigeration truck
13. Semi Trailer, Low plate semi-trailer, oil semi-trailer, van semi-trailer, bulk cement transportation semi-trailer, container semi-trailer, chemical liquid semitrailer, etc more than 300 types in total.
