Automatic Noodle Making Machine Price

NO

Production name

QTY

remark

1

Vibrating shifter

2

Power0.25kw,norm:900mm×500mm.stainless steel body and net

2

Hopper

2

Volum:0.7m³,pneumatic rorating to open the door.stainless steel made

3

Brine mixing machine

2

Power1.5KW,for pump 0.75kw,volume :1000L

4

Brine measurement device

1

Volume :130L,solution feed pump:0.75kw

5

Double spindle and dough

Kneading machine

2

Power:11kw,200kg/times, manual rorating to open the door

6

Disc maturation machine

1

Power:3kw,material plate for specification:1800mm×410mm

7

Compound mangler

1

Roll width:510mm,3groups roller machine,steel,5.5kw,for frequency conversion, stainless steel frame cover

8

Successive dough pressing

machine

1

Roller width;510mm,6 groups of roller, steel machine frame,power:5.5+5.5kw,variable frequency speed control. the imported Japanese bearing for the last press rolls

9

Single noodle steaming

Machine

1

Length:26m ,stain steel production

10

Squareness row separator

Machine

1

main transmission:1.5+1.5kw,frequency conversion, take off noodles shaft:0.25kw,fan;0.9kw*2

11

Frying machine

1

Main transmission:2.2kw,frequency conversion, vertical circulation pump:11kw,the gear pump:2.2kw,the fan knife:0.9kw,80m²spiral plate heat exchanger :1

12

Cooling machine

1

Power:1.5kw,cycloning0.37kw*12,diameter:500mm

13

Shunt conveyor

1

Main transmission:1.1kw(mechanical stepless speed)

14

Inspection conveyor

(curved conduit)

2

Main transmission:0.37kw(mechanical stepless speed)

15

Finished goods conveyor

2

Main transmission:0.37kw(mechanical stepless speed)

16

Electric control cabinet

1

Frequency control, PLC control(excluding electric power wires before the electric cabinet)

17

Install accessories random

Tools

1
