Home > Electrical & Electronics > Electric Motor > AC Motor > AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell

AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell

AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell thumbnail-1
AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell thumbnail-2
AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell photo-1
AC Motor Three Phase MS Series Motor of IEC IE2 Standards With Aluminium Shell photo-2
US$ 15 - 200 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
DELLENT
Model Number:
MS series
Type:
Asynchronous Motor
Contact Supplier Request Quote Chat Now
Fuan Dellent Electric & Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DELLENT
Model Number MS series
Type Asynchronous Motor
Frequency 50HZ , 60HZ
Output Power 0.09 KW to 20KW
Protect Feature Waterproof
Phase Three-phase
Certification CCC, CE, CCC, CE, Other, CCC, CE, CCC, CE , SGS, ISO
AC Voltage Other, 230/400V , 400V/690V
Place of Origin Fujian, China
Efficiency Other, IE1 , IE2

Specifications

MS series three phase electric motors
1, reliable quality performance
2, factory directly
3, easy maintainance
4, quiet

AC motor  three phase MS series motor of IEC IE2 standards with aluminium shell 0.09KW to 20KW

Technical Characteristics
Rated outputs and frame sizes in accordance with IEC60034 standards
Duty type S1(continuous duty)with sufficient thermal margin to withstand short overload
Enclosure protection IP55
Insulation class F, temperature rise class B
Maximum ambient 40°C
Altitude≤1000m a.s.l.

General Specifications
Terminal box rotates 4x90°
Removable feet, multi mount-terminal box left or right hand side
Enclosed shaft key

Contruction Materials

Frame – Aluminium
End shields- Aluminium/Cast iron
Fan cowl- steel
Fan-Plastic
Shaft- Medium carbon steel(stainless available on request)
Terminal box – Aluminium

Power Range 0.09 ~ 20KW
Frame Size 56 ~ 160
Enclosure: IP54,IP55
Insulation Class F,ClassB
Voltage 230/400V,400/690V
Frequency: 50Hz/60Hz
Working duty S1,S2,S3
Speed: 2 Pole , 4 Pole ,6 Pole & 8Pole

Note:

The voltage and frequency could be made according to your request.



MS Seriese electric motors technical datas

AC motor three phase MS series motor of IEC IE2 standards with aluminium shell

WHY CHOOSE US  (OUR ADVANTAGE)
WHAT WE DO AT DELLENT
• Having self-own plants producing for stators ,rotors and some related die-casting parts since from 1995
• Stamping of lamination
• Rotor die-casting
• Winding and inserting – both manual and semi-automatically
• Vacuum varnishing
• Machining shaft, housing, end shields, etc…
• Rotor balancing
• Painting – both wet paint and powder coating
• Motor assembly
• Packing
• Inspecting spare parts every processing
• 100% test after each process and final test before packing.
 WHAT DELLENT CAN DO FOR CUSTOMERS
• Dellent supplies standard products to customers.
• Dellent supplies standard products under customers’ brands and packaging, etc
• Dellent develops any new products together with the customers.



COMPANY VIEW



AC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shell









DELLETN PRODUCTS PACKING :



AC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shell






                                     CERTIFICATION
/ https://img13.fr-trading.com
AC motor three phase MS series motor of IEC IE2 standards with aluminium shellAC motor three phase MS series motor of IEC IE2 standards with aluminium shell


AC motor three phase MS series motor of IEC IE2 standards with aluminium shell



AC motor three phase MS series motor of IEC IE2 standards with aluminium shell
