Automatic Flaten Paper Roll Creasing Wooden Die Cutting Machine
Automatic Die Cutting Creasing Machine and Embossing Machine adopts micro-computer,
human-computer control interface, servo positioning, alternating current frequency converter, automatic
counting, manual pneumatic lock plate, photoelectric correcting deviation system, electromagnetic clutch,
centralized oil lubrication, overload protection and distinctive gearing. So it guarantees smooth operations
of returning paper and feeding paper, precise positioning and orderly withdrawing. All the key parts and
controls of the machine are imported products and finish machining. Such installation can realize the machine
in steady pressure, precise positioning, smooth moving, safety and reliability during the machine's operation.
Technical data:
Model NO.: |
930 model |
Cuttting precision |
+-0.10mm |
Speed |
80-120times/min |
Max. Pressure |
120tons |
Max. Cutting size |
930*530mm |
Min. Cutting size |
490*400mm |
Paper material |
100-500gsm |
Power |
11kw |
Motor power |
7.5kw |
G.W |
5000kgs |
Overall size |
4000*1700*1800mm |
