Tricolor Drinking Straw Making Machine

Specifications

1.drinking straw making machinery
ducing drink straw,nozzle,cotton,slip,lollipop stick,tooth pick,ball-pen core,watercolo







drinking straw making machine can make all kinds of drinking straws,with  single, two colors, straight or spiral strips

1.Material:PP, PE
2.Dia(mm):1-13,Len(mm):5-1,000
3.speed>250m/min capacity:35kg/h
4.Color:1,2,straight



Drinking Straws: 30,000~40,000pcs/h



   Cotton swab sticks: 80,000pcs/h



   Pen Refills: 60,000pcs/h



   Material: PP,PE



   Cutting edge: 90°/90°,90°/45°,90°/60°,45°/45°,60°/60°



   Colour:Single, Two or Three, Sprial Strips,Straight Stripes



   Operator:One operator is sufficent to run the line





 drinking straw making machine















Usage:
1.The machines are wildly used for producing drink strawnozzlecottonsliplollipop stick
tooth pickball-pen corewatercolor pen oretoy tubedroptube and other small industrial
irregular shape pipes.

2.The machine is with inverter extruding system,mould,vacuum cooling water tank or
cooling water tank,take up and cutting device etc.It make different diameter and
length straight straws.





Specification:



Model No. XG-1 XG-2 XG-3 XG-4 One color Straw Double colors straw Tricolor Straw Four Colors Straw Extruder Screw dia. 50 or 55 50 or 55 50 or 55 50 or 55 Screw L/D ratio 25:1 25:1 25:1 25:1 Motor 11kw or 15kw 11kw or 15kw+ 0.7kwx1 11kw or 15kw+ 0.7kwx2 11kw or 15kw+ 0.7kwx3 Take up and Cutting Device Inveter 0.75KW×2 0.75KW×2 0.75KW×2 0.75KW×2 Capability Extruding Output 25-35Kg 25-35Kg 25-35Kg 25-35Kg Product length ≥5mm ≥5mm ≥5mm ≥5mm Product Outer Dia. 0.8mm-8mm or 0.8mm-13mm 0.8mm-8mm or 0.8mm-13mm 0.8mm-8mm or 0.8mm-13mm 0.8mm-8mm or 0.8mm-13mm Total Weight 900 1000 1200 1300



Remark: You can choose different screw diameter and motor to make different product outer diameter.We have two types,one is to make max.diameter 8mm,another one is to make max.13mm outer diameter.thanks for your attention.
