Specifications
rattler-drying machinerylow energy consumption
reasonable structure
environment friendly
1. rattler-drying machinery :
This machine adopts low-speed rotary , curved plate hammering, dispersing the material to make the high temperature air flow current mixed with raw material to achieve the drying goal.
2. rattler-drying machinery apply raw material and industry:
It mainly applied to drying process of all kinds of powder raw material .It can be widely used in the fuel factory ,fertilizer factory, chemical factory, medicine factory and so on.
ing principle of rattler-drying machinery :
The series machine reduce the water content through the hot air from the stove, make the big moisture decrease the low moisture, until the materials can be further used.
4. rattler-drying machinery technical parameter:
Model |
Power(kw) |
Evaporation Capacity(T/H) |
GHG1.6*11*3 |
4+22 |
0.6 |
GHG1.6*25*1 |
7.5+11 |
0.8 |
GHG1.8*11*3 |
5.5+30 |
0.8 |
GHG1.8*25*1 |
11+15 |
1 |
GHG2.0*11.5*3 |
7.5+37 |
1.2 |
GHG2.2*11.5*3 |
11+45 |
1.5 |
Note |
Wood pellets,wood chips and coal as the fuel burnt in stove |
|
5. rattler-drying machinery pictures:
