Low Noise Diesel Generator

Name: Low Noise Diesel Generator
Brand: golden bull
SKU: 100961147
Availability: InStock

US$ 200 - 1,000 MOQ: 2 Sets

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

golden bull

Model Number:

5GF-LDE

Shenyang C&A Machinery I/E Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name golden bull

Model Number 5GF-LDE

Output Type AC Single Phase

Speed 3000

Frequency 50

Rated Power 5 KW

Rated Voltage 220

Rated Current 4.4

Specifications

Highly reliable yet affordable diesel generators that provide the perfect solution to the rising cost of electrical equipment.

MODEL		SILENT TYPE
		3GF-LDE		5/6GF-LDE
G E N E R A T O R	TYPE	Revolving field type 2 pole generator
	Frequency(HZ)	50	60	50	60
	ContOutput(KW)	2.8	3.3	4.2	5
	Voltage(A.C)(V)	230	240(120)	230	240(120)
	Current(A.C)(V)	12.2	13.8(27.5)	18.3	20.8(41.7)
	Engine Speed(r/min)	3000	3600	3000	3600
	Phase	Single phase
	Power factor	1
	Excitation system	Controlled Constant Self-excitation
	D.C output V/A	12V/8.3A
	Operation Capacity	12 hour Constant Operation
	Coupling Pattem	Straight shaft coupling
E N G I N E	Model	178FGE		186FGE
	Type	Direct injection Vertical,4-cycle,air-cooled diesel engine
	Displacement cc(cu.in.)	296(18.06)		406(24.78)
	Max.output(KW/rpm)	4.4	4.6	6.6	7.35
	Cont.output(KW/rpm)	4	4.4	5.9	6.6
	Starting system	Recoil
	Govemor system	Centrfugal weight system
	Fuel	Diesel light fuel(BS-AL or equivalent)
	Fuel tank capacity(L)	13.5		16
	Lube oil capacity(L)	1.1		1.65
	Bore x Stroke(mm)	78*62		86*70
	Protection System	Low oil,Waming System/Stop Device(not for L-series)
UNIT	Noise level at 7m dB(A)	70
	dimensions(LxWxH)mm	840520640		905520680
	Dry weight(kg)	126		165
