HSY-FS4500 Window USB interface durable quality fingerprint reader capture finger print image scanner fingerprint sensor
USB fingerprint sensor Introduction:
FS4500 is a stable and excellent fingerprint reader.
The device can capture fingerprint image and upload e to the PC by USB interface.
FS4500 supports most of the Windows OS, including Window xp, vista and Windows 7(32bit).
We provide developer with SDK. The developer can integrate the FS4500 hardware with their own system.
This product is widely used in social insurance, public security, time attendance, fingerprint encryption,
embedded system and other fields of application.
USB fingerprint sensor Features:
· High-performance, maintenance-free optical fingerprint sensor
· Readily accessible for any finger
· High quality industrial-class ABS plastic material with scratchproof texture surface
· treatment
· Removable weighted stand
· High speed USB interface
· LED indicates the status of the device
· Driver CD included
· Available SDK for secondary development
. ISO 9001:2000 standards; FCC Class B, CE, ICES, BSMI, MIC USB, WHQL approved standard
USB fingerprint sensor Specification:
| Model No. | HSY-FS4500 |
| Fingerprint sensor | optical |
| Interface | USB |
| Resolution | 512 DPI / 256 gray |
| USB Cable | 150 CM |
| Sensing Area | 15*20mm |
| Color | Black |
| Image Size | 280*360pixel |
| Support O/S | Windows XP and Vista, windows 7(32bit) |
| Operating Humidity | 20-80% |
| Operating Temperature | 0°-55°C / 32-131°F |
| Dimension (WxLxH) | 65.5*49*79.8MM |
| ISO 9001 | 2000 standards |
| Weight | 0.20kg |
USB fingerprint sensor shows:
Installation Instruction:
1. Connect the usb cable with the card reader to the computer USB port.
2. The reader will 'drip' sound and flash about that power successfully,
and then half a second after the 'drip' sound and flash about that device self-test successfully, without Install any drivers, windows will automatically recognize it.
3. Open one EXCEL or WORLD ,the card number would be input by self .
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;
2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;
3. Support Customers specifying freight forwarders or selected shipping methods!
4. Delivery Time: 2~7 working days. Accurate deliver based on your quantity .
