Outdoor NLOS COFDM Wireless Video Transmitter Receiver

Name: Outdoor NLOS COFDM Wireless Video Transmitter Receiver
Brand: LinkAV
SKU: 100944401
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

LinkAV

Model Number:

C331S+C331R

Shenzhen Zhongchuang Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name LinkAV

Model Number C331S+C331R

LinkAV wireless transmission system advantages:

LinkAV-C331S Transmitter

Product Features:

Technical Parameters:

Items	Description
Modulation Type	QPSK(4QAM), 16QAM, 64QAM
Working Frequency	300-900MHz;0.5M per step for adjustment
Transmission Power Rate	43dBm
RF Bandwidth	2/3/4/5/6/7/8MHz adjustable
FEC(Forward Error Correction)	1/2,2/3,3/4,7/8
Guard Interval	1/4,1/8,1/16,1/32
Video Input	CVBS
Video Compression	MPEG-2
Audio Interface	AV, headphone
RF Interface	N F Head
Parameter Control Method	digital adjustable LED control panel
Transmission Distance	Above 25 Kilometers
Encryption Method	128 - bit AES (with modulation board)
Power supply	AC220V
Battery	1.2A
Operating Environment	-10~70℃
Dimensions	42033588.8(mm)

LinkAV-C331R Receiver:

Product Features:

1. Dynamic range: 20dbuv~104dbuv;

2. Decryption style can be automatically tracked;

3. Authorized receiving and encrypted capabilities;

4. Output Interface: A/V, USB support MODEM or Ethernet Interface;

5. Output Interface: parallel interface;

6.19" 1Ustandard

Receiver C331R Technical Parameters:

Item C331R	Description
Modulation Type	COFDM
Output Frequency	46MHz~860MHz, per 0.5MHz adjustable
Working Bandwidth	2/3/4/5/6/7/8MHz
Receiving Sensitivity	-106dBm
Video Output	BNC interface for SD analogue output
Video Output	HDMI HD digital output
Audio Output	BNC
Forward Error	1/2,2/3,3/4,7/8
Guard Interval	1/32,1/16,1/8,1/4
Video Compression	MPEG-2 /H.264
Parameter Control	Adjustable digital LED control panel
RF Interface	N Female Head
Power Supply	AC220V
Encryption Method	AES 128, can set user’s password
Work Temperature	-10~70℃
Overall Dimensions	1U
