LinkAV wireless transmission system advantages:
- Long range transmission distance
- Real-time transmission systems
- Delay time very short less than 500ms
- Perfect image quality, brighter colors and image smoothness.
T321S-1W Bi-directional Wireless Long Range Transmitter System
Product Features:
- Modularized, three proof, low-power consumption design;
- Support system with frequency or inter frequency networking; automatic roaming
- Stable power, adjustable dynamic power rate;
- Encryption: AES 128 bit, can set user’s password;
- IP NLOS transparent data transmission;
Technical Parameters:
Item |
Description |
Working Frequency |
300~800MHz(Customized) |
RF Bandwidth |
2 / 4 / 8MHz |
Modulation Type |
TDD-OFDM |
Communication Method |
TDMA Full Duplex |
Power Output |
≤30dBm |
Band Flatness |
≤ ±0.5dB |
Spurious Spectrum |
≤ -36dBm |
Third-order IMD |
≤ -36dBC |
Receiving Sensitivity |
≤ -100dBm |
Anti-adjacent Frequency Interfere |
≥ 40dB |
Synchronization Control |
GPS |
Network Protocol |
IP/TCP,UDP,HTTP,SMTP etc |
Video Compression |
H.264 |
Video Format |
CIF/D1/720P |
Video Encoding |
64Kbps G.711 |
Audio Input |
Two-channel 12dBm |
Work Temperature |
-30 ~ +70°C |
Battery(12V/7800mA) |
Over 5 Hours |
Power Input |
DC:10V ~ 16V |
Power Consumption |
15 ~ 30W |
Size |
54*128*220(mm) |
Net Weight |
1.7Kg |
Audio Interface |
BNC video Input ,3.5mm Standard headset, 2.5mm output audio |
Control system data connection |
RS232 |
RF Antenna Terminal |
RF Head |
Network Interface |
RJ45 |
