LinkAV wireless transmission system advantages:
- 1. Long range transmission distance
- 2. Real-time transmission systems
- 3. Delay time very short less than 500ms
- 4. Perfect image quality, brighter colors and image smoothness.
Vehicle - Mountable TDD Wireless Car Transmitter for Protection 10 Watts
Product Features:
- Modularized, low power, built-in cooling fan
- Support system with frequency or inter frequency networking, automatic roaming
- Stable power and adjustable dynamic power
- NLOS transparent IP data transmission
- Encryption: AES 128 bit, dual mode positioning
Technical Parameters:
Item |
T331-10W |
|
|
RF Parameter |
Working Frequency |
300~800MHz |
|
Modulation Bandwidth |
2 / 4 / 8MHz |
|
|
Modulation Type |
TDD-OFDM |
|
|
Communication Mode |
TDMA Full Duplex |
|
|
Power Output |
≤43dBm |
|
|
Band Flatness |
≤ ±0.5dB |
|
|
Spurious Spectrum |
≤ -36dBm |
|
|
Third-order IMD |
≤ -36dBC |
|
|
Receiving Sensitivity |
≤ -100dBm |
|
|
MER |
≥ 36dB |
|
|
Anti-adjacent Frequency Interfere |
≥ 40dB |
|
|
Data |
Synchronization Control |
GPS/Beidou with Synchronized clock |
|
Transmission Bandwidth |
Up to14Mbps |
|
|
Network Protocol |
IP/TCP,UDP,HTTP,SMTP etc |
|
|
Encoding |
Video Compression |
H.264 |
|
Picture Format |
CIF/D1/720P |
|
|
Audio Encoding |
64Kbps G.711 |
|
|
Audio Input |
Dual Channel 12dBm |
|
|
Generic Specification |
Power Supply |
~100 – 260VAC |
|
Power Consumption |
≤50W |
|
|
Dimensions |
2U |
|
|
Net Weight |
≤10Kg |
|
|
Connector |
AV Input |
BNC,SDI or HDMI |
|
Power Connector |
3 Pin Connector |
|
|
