filter for food and beverage

 1.What is ceramic membrane?

filter for food and beverage

Ceramic membrane is a porous fine ceramic filter which is sintered from Alumina Titanic or Zirconium under ultra high temperature. Ceramic membrane normally has an asymmetrical structure with porous support active membrane layer. The macro porous support ensures the mechanical resistance while the active layer functions separation ranging from Microfiltration, Ultr afilatration and even Nano filtration (from 10μm down to 1KD). Ceramic Membrane always runs at a CROSS FLOW FILTRATION mode. The turbid fluid goes through membrane layer inside the single channel or a multi channel at a high velocity. Driven by pressure, the clean liquid with micro-molecule pass through the membrane layer vertically to permeation, the solid and big molecule is rejected in retentate. The feed fluid is thus clarified,concentrated and purified.
Compared with normal traditional filters like Filter Press, Centrifuge and DE Filter, Ceramic Membrane Filters have many unique advantages:
*Excellent resistance to acid/alkaline and oxidation chemicals
*Solvent stability
*High thermal stability
*Fine separability with narrow pore size distribution
*Excellent mechanical and abrasive resistance
*Extremely long work life
*Easy to be cleaned and sanitized with backflushing

2.What is  lab scale experimental equipment of ceramic membrane

It’s a kind of mini and simple filtration system used for pilot trials and membrane application development study, and supply useful information for project design. Various size and model be available.

Features:

1.       Type of membrane :ceramic MF/UF membrane and spiral/hollow fiber 2.5’/4.0’membrane

2.       Membrane areas:0.1 square meters ,0.2square meters,0.4square meters ,0.8square                           meters,1.5square meters,3.0square meters,9.0square meters

3.       Main components :membrane, housing, feed tank, centrifugal pump, flow/pressure/temperature           meter, back flush tank,  electric panel, valves and pipe

4.       Materials of bodies;SUS304,SUS316L,Titanium,FRPP,UPVC

5.       Material of seals: EPDM, Fluoro rubber, silicon

3.Applications

1. Biochemical and Pharmaceutical Industries: Clarification of fermentation
    Liquids, purification and separation of Chinese medicine.

2. Environment Protecting Engineering: Clarification and separation of turbid water and wastewater.

3. Food Industry: Micro filtration of milk, clarification of fruit juice, separation
    Of soybean protein, Palm oil concentration.

4. Petrochemical Industry.

5. Other Fields: Reclaim and collection of nano-powders, and catalyze, filtration of acid/alkali liquids, membrane bio-reactor.

 4.Application:Apple juice

Industry type:Beverage

Objectives:

Simplify the traditional process for the clarification of the apple juice.

Our Solution:

Micro or ultrafiltration ceramic membrane INSIDE CéRAM? allows the clarification of apple juice by the replacement of classical coagulation and dead end filtration steps.
The filtration splits the juice into two parts:

- a clear juice (the permeate) for bottling or concentration.
- a retentate with less than 3 % of the initial volume.

Advantages:

- Increase the yield of clarification (97 % for this process against 90 for the classical process).

- Removal of traditional dead end filtration unit.
- Reduction of consumption of products (enzyme, diatomic earth, and cellulose plates).

 Nanjing Create Dream Import & Export Trade Co., Ltd. is a trader specialized in the research, development and production of ceramic membranes.We are located in Nanjing, with convenient transportation access. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in communications industry and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

1.Can I negotiate the price?

Yes,we will consider the discounts based on your order quantity.

2.What’s your minimum order requirement?

 MOQ for our products is 1 set machine,we could send it to your country port

if you tell detail information about your country port.

3.How long will you prepare the goods?

Generally, it’s about one month. But it finally according to the order quantity and product type.

4.How can I know my order’s production progress?

We will keep on eyes on the production progress, and inform you when start producing and shipping.
