corrugated box manufacturing machinery
- 100 Set / Sets per Month
- qingdao
- T/T Credit Card
- Scented teatriangle package packaging machine Inside and outside bag packaging line
- Give bag packaging machine Between-meal nibblespackaging line
- Internal and external package linkage line Green teatriangle package packaging machine
- Triangle package packaging machine Green teapackaging linkage line
- Between-meal nibblesgive bag packaging machine The five metalsbag packing machine
- Black teatriangle package packaging machine Packaging linkage line
Product Details
Condition: | New | Application: | Apparel, Chemical, Commodity, Other, Apparel, Chemical, Commodity, Machinery & Hardware | Packaging Type: | Cartons |
Packaging Material: | Plastic, Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 350KW | Place of Origin: | Shandong, China |
Brand Name: | biture | Model Number: | corrugated box manufacturing machinery | Dimension(L*W*H): | costomized |
Weight: | costomized | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
corrugated box manufacturing machinery
The description of corrugated box manufacturing machinery:
This production line is available in large amount automatic production, which can produce corrugated paperboard correspond to national standard with high quality, and adopted concentrated control, operated and repaired easily, safely, reliable, reducing manpower, This production line adopts international energy can save technology with oil heating, which can save 40 percents energy than steam heating, So this can reduce costs effectively. It's an economical production in big, middle paperboard company.
1. Total Length: 40-55m
2. Total Power: 55kw
3. Two kind of frame with shaft and frame without shaft, provide the customer with the choice.
4. Corrugated paperboard marching: diameter of corrugated roller: 240-320mm, electric adjust speed motor used.
5. Double cylinder gum mounting machine: On the adoption, inside two layers draw the gun, can carry the paper lead the paper roller.
6. Oven: total length 7.8m, combined with 9-13 heating flocks.
7. Setting Part: total length 3.8-5 m, combined with some pairs of symmetrical shafts.
8. Horizontal, Length uays slicing machine: Common knife or super thin knife selected based on customer's demand, high automatically, handy operating.
9. Boiler: consumption of cad: 50kg/h , conventional pressure, almost no oil consumption as temperature raised from 0oC to working temperature in a hour.
features of corrugated box manufacturing machinery:
1. Cardboard size adjustment adopts screw roller adjusting system, one man operating, simple and fast.
2. Available for adjustable paper platform, more adaptable for kinds of cardboard, stable and precise paper feeding.
3. Adopts advanced seamless rubber strap, which has big friction, long life, low voice, easy maintenance and high economic efficiency.
4. Double stretch power control, convenient and reliable.
5. Transmission roll adopts decorative design roll, which increase the friction between strap and roll, ensure stable and fast cardboard feeding.
6. This machine includes electric and magnetic clutch separating brake system.
7. This machine adopts PLC auto program control, so it has high automatic extent.
8. Frequency converter drives motor to realize stable velocity change operating.
9. Light and electric signal brakes by PLC control power and magnetic clutch to keep pace with the main engine.
Printing unit of corrugated box manufacturing machinery:
Printing roller
1. High quality steel production, surface grinding, hard chromium plating. Static balance correction, smooth operation, adapt to the high-speed running of the machine.
2. Roll is grooved, convenient to release.
3. Ratchet fixed volume edition axis. Suitable for standard hanging slats, change plate quickly.
4. Adjust the printing roller electric 360 degree, digital automatic display adjustment quantity.
5. Install foot switch to control the positive and negative run of the drum, convenient to change plate.
6. Automatic return to zero function.
7. The printing roller axial direction is manual setting, the maximum move range is±10 mm.
Pressing roller
1. Adopt high quantity seamless tube, dynamic balance correction, smooth operation.
2. Surface grinding and hard chrome plating.
3 Gear with no side gap regulating mechanism, the adjustment does not affect the gear mesh, guarantee transmission accuracy.
Anilox roller
1. Anilox roller adopts Haili.
2. Made by professional factory.
3. Metal mesh count: from 180-250 line/inch, selected by the customer.
4. Air pressure type anilox roller with automatic lifting and idling devices.
Rubber roller
1. Rubber roller adopts Jiangsu Changzhou Dongjun.
2. Made by professional factory, guarantee quality.
3. Overrunning clutch and automatic idle device to prevent ink dry.
4. Rubber roller is waist drum type, to ensure the quality of distributing.
5. Rapid clearance of fine-tuning self-locking device, ensure uniform inking.
6. Independent uniform ink roller drive mechanism, to ensure uniform ink quality.
Electrical control of corrugated box manufacturing machinery:
Electrical control system uses the microcomputer control, realized visual display from the feeding, die cutting, delivery each working state and troubleshooting method. With various safety devices to guarantee machine and human safety. Imported Japan Stepless Inverter-controlled main motor. Efficiency enhancement type high power, low energy consumption, lower noise.
The machine adopts Japan OMRON PLC program control, all kinds of electrical components, the detection switch are used German Siemens, French Schneider and other famous international brands, making the performance more stable and reliable. All electronic components are CE standard.
