GS500 Automatic Hydraulic Horizontal CNC metal cut band saw machine used portable saw mill
- 100 Set / Sets per Month
- Qingdao & Tianjin Port China
- T/T L/C D/P D/A Credit Card PayPal
- REBOUND CNC plasma cutting machinery with bevel head 30mm
- REBOUND cnc detachable gantry plasma and flame cutting machinery sheet
- Best price cnc detachable plasma cutting machinery for gas-plasma cutting
- helical rack and pinion cnc detachable plasma cutting machinery automatic high safety level
- pump inside air detachable plasma cutting machinery sliding work bench
- solenoid valve for detachable plasma cutting machinery lokermann high safety level
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | NR |
Model Number: | GS500 | Voltage: | 380V 50HZ | Rated Power: | 5.5 KW |
Dimension(L*W*H): | 2800*2300*1850mm | Weight: | 2800 KG | Certification: | CE |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
GS500 Automatic Hydraulic Horizontal CNC metal cut band saw machine used portable saw mill
1. 16 years production experiences
2. EC & ISO certificates
3. Introduce Taiwan Technology
4. Provide customized & OEM service
5. Fast delivery
France customers coming for saw machine testing
Main features:
1.Automatic NC Saw Suitable for sawing and cutting materials into same-sized work-pieces in massive
2.PLC control system,which can accommodate a group or several groups of data and continuous cutting.
3.Man-machine interface instead of the traditional control panel, in digital way parameters.
4.Manual and automatic duplex option.
5.Imports grating used to control foot length,high accuracy.
Capacity Round: | 500mm |
Capacity Rectangular: | 500 X 500 mm |
Blade Size (Length/Width/Thickness): | 5550×41×1.3mm |
Power Requirement | 380V,5 0HZ |
Main Motor Rate | 5.5 KW |
Oil Pump motor rate | 1.5KW |
Coolant Pump rate | 0.12KW |
Blade speed(m/min): | 36/54/72 |
Maximum Vise Opening: | 520mm |
Shipping weight | 2800KG |
Shipping dimensions | 2800X2300X1850MM |
the front display
the back display
the left display
the right display in yellow colour
The spare parts display
We are the professional metal band sawing machine manufacturer from china.we began our business in the year of 1998.Unitll now we have 2 brands-NR&JF,we have many years experience in manufacturing metal band sawing machine,all our products have been CE&ISO certificated.we have the strong capacity in R&D,Design and manufacturing.our main products include two-column band sawing machine,angle band sawing machine,NC band sawing machine,Vertical band sawing machine and spectral grinding machine,etc.with advanced technology and competitive prices,our products sell well in china as well in the world .
After sales service:
2. Free training to make sure a master of the operating of cnc router for the person who come to our factory
Finally:
We would like to and ready to do business with any company from all over the world. If you have interests in our products, please don't hesitate to contact with us, we would like to give you the best service any time!
