230V 60ohm High Quanlity China Ceramic Igniter for Biomass Burners

Specifications

1.Igniter for pellet burner
2.Fast heating up
3.High temperature
4.Long life
5.Meet Rohs



We are the professional ceramic igniter manufacturer for biomass buners with the advantages

of long service time, fast heating rate, energy-efficient and eco-friendly.





Our ceramic heating elements consist of AL2O3 insulation ceramics with an integrated platinum

conductor, and reach to a permanent operating temperature between 800°C and 1100°C



Ceramic hot surface igniters for pellet boilers need only approx. 1/10 of the energy of that needed

by hot air fans and ignition blowers. Their ignition capacity lies between 120 and 200 Watt. Depend-

ing on the positioning of the ignition element in the boiler, the ignition time of approx. 60 seconds is extremely short. This also means minimal emissions!



 Application

One special application area for the high-temperature heaters is in heating systems that use

solid fuels such as wood pellets as the energy source. The challenge here is to ignite the biomass

in a very short time while retaining very low emission values. This can only be achieved with a

sufficiently high ignition temperature.1000°C, heats up the supply air in the shortest possible time

to an extremely high temperature.



Our hot surface igniters are perfectly suited for this purpose. This special geometry of the cylindrical ceramic heaters, in combination with an extremely high surface temperature.



Igniting wood chips, firewood, coal bricks or other biomass (such as corn, etc.) is possible.



 Mass customization is available.
