P6 stair indoor full color advertising led screen

Features:

1>Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.

2>High flexibility: our company has made researches on various outdoor circumstances, and applied the research achievements to design systems, so as to obviously improve both the flexibility and reliability of out products in various bad circumstances outdoors.

3>Rich colors: with three basic colors (red, green and blue) to form the unit boxes, 256-level gradation of red, green and blue form 16777216 kinds of colors, making the electronic displays showing rich colors, high saturation, and high resolution, and also enabling them to show high frequency dynamic images.

4>High brightness: the products adopt super-high brightness LED, so that you can see clearly from a long distance even in strong sunshine.

5>High reliability: the products adopt the static scanning technology and the module design technology to offer higher reliability and stability.

6>Good effect: the products adopt non-linear calibration technology to realize clearer images with stronger feeling of layers.

7>Easy operation: the products adopt popular video playing software to facilitate system operations

number

Item name

Parameter and index

unit module

1

LED encapsulation mode

SMD3528 Surface mounted

2

Horizontal axis

160°

3

Vertical axis

160°

4

Pixel composition

1R1G1B

5

Pixel pitch

6mm

6

Scan method

1/8

7

Drive method

Constant current

8

Module resolution

32×32 pixels

9

Module dimensions

192mm×192mm

10

Module type

incorporated lamp and drive

11

Module working voltage

+5V

12

Module average power

6.25W

13

Module maximum power

25W

14

Module shell material

PC

15

Module mask material

PC

unit cabinet

1

Module layout

4×4 pieces

2

Cabinet resolution

128×128 pixels

3

Cabinet maximum power

500W

4

Cabinet average power

125W

5

Cabinet dimension

1024mm×768mm

6

Cabinet material

steel/aluminum alloy

7

Cabinet color

black/gray

8

Protection grade (front/back)

IP65/IP54

Entire screen

1

Application environment

indoor

2

Brightness

>1800 mcd

3

White balance coordinates

X=0.29,Y=0.31

4

contrast

64000:1

5

Color temperature

8000K

6

Pixel density(pixels/m²)

27777

7

Average consumption(W/m²)

212

8

Maximum consumption(W/m²)

848

9

Power source

AC220V/50HZ or AC110V/60HZ

10

Operating temperature

-20°C~ +50°C

11

Operating humidity

10%~90%

12

Storage humidity

-30°C ~ +50°C

13

Refresh frame rate

60Hz

14

Refresh rate

480Hz

15

Viewing distance

6-100m

16

grayscale/color

16.7M

17

Brightness adjustment

100 manual levels /100 auto levels

18

Control method

synchronous with the computer display

19

Data transfer range

Network c able:100m

20

Computer operating system

WINDOWS(98,2000,XP,Vista,7)

21

Video signal

VGA,DVI,RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION and so on.

22

MTBF

≥10000 hours

23

Longevity

≥100000 hours

24

Certification

UL/CE/CCC
