Home > Products > Mobile &Truck LED Display > Outdoor advertising full color truck /car mobile LED display
Outdoor advertising full color truck /car mobile LED display
- 3000 Square Meter / Square Meters per Month
- Zhongshan; Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | SkyMax Display | Model Number: | SM-P16 Mobile LED Display Series |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | 16mm |
Product Description
Specifications
Mobile LED Display:>Fast set-up,easy moving
>Adopted for the picture adjustment
>Can be maintained by single pixel
We offer an unrivalled choice of Mobile LED display hire options, ensuring you have the perfect big screen to suit your event.
|
Product description:
1). P16mm mobile LED Display has high level waterproof and anti-dust function of Ip65. 2). The structure is simple, standard cabinet. Big module design, and professional corner design to ensure the screen can be installed without any gap and ad a mirror. 3). International aluminum material or the thin roll steel plate of 1.2mm adopted in cabinet material. Which is durable and never has a transformation. 4). True quality, stable performance and easy operation model. 5). This product has high ,middle, low grade three price levels for choosing. 6). Supports the usual VGA and DVI traditional video signal, it also specially supports HDMI video signal, and so on, in addition, it can receive and show video programs, such as TV programs,VCD or DVD,live programs, and so on. |
Technical parameter:
number | Item name | Parameter and index |
unit module | ||
1 | LED encapsulation mode | φ4oval DIP |
2 | Horizontal axis | 120° |
3 | Vertical axis | 60° |
4 | Pixel composition | 1R1G1B |
5 | Pixel pitch | 16mm |
6 |
| |
7 | Scan method | 1/2 |
8 | Drive method | Constant current |
9 | Module resolution | 16×8 pixels |
10 |
| |
11 | Module dimensions | 256mm×128mm |
12 | Module type | incorporated lamp and drive |
13 | Module working voltage | +5V |
14 | Module average power | 9W |
15 | Module maximum power | 36W |
16 | Module shell material | PC |
17 | Module mask material | PC |
unit cabinet | ||
1 | Module layout | 4×6 pieces |
2 | Cabinet resolution | 64×48 pixels |
3 |
| |
4 | Cabinet maximum power | 1080W |
5 | Cabinet average power | 270W |
7 | Cabinet material | steel/aluminum alloy |
8 | Cabinet color | black/gray |
9 | Protection grade (front/back) | IP65/IP54 |
Entire screen | ||
2 | Brightness | >8000 cd/m2 |
4 | contrast | 64000:1 |
5 | Color temperature | 8000K |
6 | Pixel density(pixels/ m2) | 3960 |
7 | Average consumption | 343 (W/m2) |
8 | Maximum consumption | 1373 (W/m2) |
9 | Power source | AC220V/50HZ or AC110V/60HZ |
12 | Storage humidity | -30°C ~ +50°C |
14 | Refresh rate | 480Hz |
15 | Viewing distance | 15-300m |
16 | grayscale/color | 16.7M |
17 | Brightness adjustment | 100 manual levels /100 auto levels |
18 | Control method | synchronous with the computer display |
19 | Data transfer range | Network cable:100m |
21 | Video signal | VGA, DVI,RF S-Video, RGB, RGBHV, YUV, YC,COMPOSITION and so on. |
22 |
| |
23 | Longevity | ≥100000 hours |
24 | Certification | UL/CE/CCC/ROHS/ISO9001:2008 |
