High Brightness Outdoor LED Moving Signage

Specifications

>Brightness: >3000mcd
>Single color
>Display simple image,time,Temperature,text,graphic,digit etc.
>Control:3G/GSM/GPRS..

Outdoor RGB LED Moving Signage:





>>It are manufactured to withstand outdoor conditions such as large temperature variations, rain, snow and dust. Outdoor LED moving boards are brighter than semi-outdoor LED Message Sings as they should be visible from afar (for example, from a fast moving car down the road).

>>Different sizes and colors are available that fit your flexible wants and needs.

>>It is easy to operate, high clarity digit.









Parameter:



Sequence Number	Item Parameter	P12 Outdoor Single Color
01	Size of Pixel Diameter(mm)	4
02	Pitch of Pixel(mm)	12
03	Quantity	1R
04	Colors	1
05	Brightness(mcd)	>3000
07	Frame Rate(Hz/s)	128
08	Refresh Rate(Hz)	240
09	LED Life-span(hour)	80,000
10	Mean Time Between Failures(hour)	50,000
11	Viewing Angle (horizontal axis)	>1600
12	Viewing Angle(vertical axis)	>600
13	Data Transfer Range	RS485(1.2KM)/RS232(15m)/GSM/GPS
14	Viewing Distance (m)	12--150
15	Module Dimensions W x H(mm)	192x192
16	Module Resolution W x H(pixel)	16x16
17	Maximum Power Consumption   of the Module(W)	10
18	Average Power Consumption   of the Module(W)	2
19	Pixel Density(pexels/m2)	10000

















Detail about this product:

Acreage : 0.96*0.384 m²

Quantity: 52 piece

Screen Resolution: 80*32 pixel

Scan method: 1/4

Module quantity: 520 peice

Cabinet size: 960mm* 384mm

Wateproof: IP65 (Front); IP54 (Back)

Guarantee : 3 years

Certificate: CE

This LED Message Sign was producted for customer who are from Australia July, 17 2012









Picture show:















                                                                 Side



















 Workshop show:
