Specifications
Outdoor LED Screen :>Used imported Germany PC material
>Stable capability
>Best factory price
>Design special
Parameters:
Pixel pitch |
16 mm |
Cabinet size |
1024 x 768 x 200 mm |
Cabinet true resolution |
64 dots x 48 dots |
Cabinet virtual resolution |
128 dots x 96 dots |
Cabinet max. power consumption |
845 watts |
Screen total cabinets |
24pcs |
Screen true resolution |
384 dots x 192 dots |
Screen virtual resolution |
768 dots x 384 dots |
Screen Brightness |
10000 cd/m2 |
Screen average Power |
5225 watts |
Screen max. power consumption |
20800 watts |
Power source |
220V / 60Hz (± 10%) |
Power source certification |
UL/ CE/ FCC /ROHS /ISO9001:2008 |
Screen operating temperature |
-25-----+45 °C |
Screen operating humidity |
≤ 90% R.H. |
Data transfer cable |
100M/network cable, 15km/fiber |
Our latest systems benefit from many upgrades which now give us a competitive edge in the market place.
1. Smaller lighter cabinets (making them ideal for easy portable)
2. Soft rubber mask (facial)-durable during impact
3. Quick fix supporting feet (simple action)-see picture
4. Special plastic cover
5. Simple cable connections-see picture
6. Corrosion resistant coatings (extreme weather conditions)
7. Special interlocking cables-do not pop off during impact
8. Cabinet front IP67-Cabinet rear IP54
9. Upgraded conformal coatings (extreme weatherproof)
10. Improved air circulation- cooling within the housing
11. Improved control system and data connections
12. Fewer operating cables-simple connections.
in Brno (which is the second largest city in Czech and approximately 150 kilometres east of Prague) - our employees are finishing the installation of the big display there, consisting of 2 P16 displays connected together, which will be visible from the busiest highway in Czech;
then in Olomouc, which is a smaller city not far from Brno and then in Kladno, which is a smaller industrial city but very close to Prague, particularly to the international airport in Prague - it takes less then 15 minutes by car to get to Kladno from the airport and about 40 minutes from the center of Prague.
Smaller lighter rental cabinets (making them ideal for easy portable)
Normally cabinet of Sport Perimeter LED Display with 2 meter long or 4 meter long.
But our P16 cabinet will be 1.024 meter long, This very smaller than the normal one. It's more convenience to move the cabinet by two person.
More over, our cabinet made by the material of aluminum alloy. It's very lighter weight.
Soft rubber mask (facial)-durable during impact:
Specially designed rubber mask with soft and flexible material.
Impact resistance:
Safe for players and against impact of ball, or other projectiles for fans or else.
Quick fix supporting feet (simple action):
Each supporting foot has the screw holes, angle of the cabinet is adjustable by fixing the supporting feet.
The supporting feet is quick and simple to operate and allows the cabinet to adjust to different angles for better results on TV broadcasts.
The pulldown rear back-support feet design enables easy transportation for packing and installation.
Special plastic cover:
The rental cabinet has top pin of the connection part. See the right picture showing.
As the top pin is very dangerous if player or fans hitting. So we have the good way to use the special plastic cover to around the pin and avoid the accident happen.
Simple cable connections:
power and data transfer from cabinet to cabinet, we use the aviation plug power cable and network cable. Both of this two cable has the waterproof function. And they are very short, around 15cm long. Not only shows the simple operating but also avoid the troubles from the long cables.
Improved control system and data connections:
Perimeter advertising display software is specially designed to show image. Our special software and controller system can control 2048 dots x 1536 dots.
That means our control system with software can control around 250pcs cabinets for P16.
Our projects show:
