Specifications
1.We are professional manufacturer of led video display..2.Excellent effect,advanced technology.
3.Good effect and price.
P7.62 Indoor full color LED display is one type that has high clearly show to be used for indoor. It adopts the unique SMD 3528 technology, each lighting unit has red ,green and blue color. The color can be showed reach 10.7 billions. They can play colorful static and animate images .They support VGA ,DVI traditional video signal, especially can used HDMI. Points of LED screen are corresponding with points of computers, can display TV program, VCD, DVD, live show.
P7.62 Indoor full color LED display adopts Fully automated production, realizable quality .Color saturation, high brightness, lower power consumption, long life, large perspectives.This kind of display is widely used showroom, coffee bar, stadium and hotel for information display.
number |
Item name |
Parameter and index |
unit module | ||
1 |
LED encapsulation mode |
SMD 3528 Surface mounted |
2 |
Horizontal axis |
160° |
3 |
Vertical axis |
160° |
4 |
Pixel composition |
1R1G1B |
5 |
Pixel pitch |
7.62mm |
6 |
Scan method |
1/8 Scan |
7 |
Drive method |
Constant current |
8 |
Module resolution |
32dots× 16dots |
9 |
Module dimensions |
243.84x121.92mm |
10 |
Module type |
Synergetic lamp and drive |
11 |
Module working voltage |
+5V |
12 |
Average Power Consumption |
5W |
13 |
Cabinet Maximum Power Consumption |
20W |
14 |
Module shell material |
PC |
15 |
Module mask material |
PC |
unit cabinet | ||
1 |
Module layout |
3×6 pieces |
2 |
Cabinet resolution |
96dots× 96dots |
3 |
Cabinet maximum power |
450W |
4 |
Cabinet average power |
113W |
5 |
Cabinet dimension |
731.52mm×731.52mm |
6 |
Cabinet material |
steel/aluminum alloy |
7 |
Cabinet color |
black/gray |
Entire screen | ||
1 |
Application environment |
indoor |
2 |
White balance brightness |
>1600cd/m 2 |
3 |
White balance coordinates |
X=0.29,Y=0.31 |
4 |
contrast |
64000:1 |
5 |
Color temperature |
8000K |
6 |
Pixel density |
17222 pixels/m |
7 |
Average consumption |
210 W/m2 |
8 |
Maximum consumption |
841 W/m 2 |
9 |
Power source |
AC220V/50HZ or AC110V/60HZ |
10 |
Operating temperature |
-10°c- +45°c |
11 |
Operating humidity |
10-90 |
12 |
Storage humidity |
-30°c -+50°c |
13 |
Refresh frame rate |
60Hz |
14 |
Refresh rate |
480Hz |
15 |
Viewing distance |
7-100m |
16 |
grayscale/color |
16.7M |
17 |
Brightness adjustment |
100 manual levels /100 auto levels |
18 |
Control method |
synchronous with the computer display |
19 |
signal transfer distance |
Network cable:100m |
20 |
Computer operating system |
WINDOWS (98; 2000; XP; Vista; 7) |
21 |
Video signal |
VGA,DVI,RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION and so on. |
22 |
MTBF |
≥10000 hours |
23 |
Longevity |
≥100000 hours |
24 |
Certification |
UL/CE/CCC |
