P7.62 indoor advertising led video board

number

Item name

Parameter and index

unit module

1

LED encapsulation mode

SMD 3528 Surface mounted

2

Horizontal axis

160°

3

Vertical axis

160°

4

Pixel composition

1R1G1B

5

Pixel pitch

7.62mm

6

Scan method

1/8 Scan

7

Drive method

Constant current

8

Module resolution

32dots× 16dots

9

Module dimensions

243.84x121.92mm

10

Module type

Synergetic lamp and drive

11

Module working voltage

+5V

12

Average Power Consumption

5W

13

Cabinet Maximum Power Consumption

20W

14

Module shell material

PC

15

Module mask material

PC

unit cabinet

1

Module layout

3×6 pieces

2

Cabinet resolution

96dots× 96dots

3

Cabinet maximum power

450W

4

Cabinet average power

113W

5

Cabinet dimension

731.52mm×731.52mm

6

Cabinet material

steel/aluminum alloy

7

Cabinet color

black/gray

Entire screen

1

Application environment

indoor

2

White balance brightness

>1600cd/m ²

3

White balance coordinates

X=0.29,Y=0.31

4

contrast

64000:1

5

Color temperature

8000K

6

Pixel density

17222 pixels/m

7

Average consumption

210 W/m²

8

Maximum consumption

841 W/m ²

9

Power source

AC220V/50HZ or AC110V/60HZ

10

Operating temperature

-10°c- +45°c

11

Operating humidity

10-90

12

Storage humidity

-30°c -+50°c

13

Refresh frame rate

60Hz

14

Refresh rate

480Hz

15

Viewing distance

7-100m

16

grayscale/color

16.7M

17

Brightness adjustment

100 manual levels /100 auto levels

18

Control method

synchronous with the computer display

19

signal transfer distance

Network cable:100m

20

Computer operating system

WINDOWS (98; 2000; XP; Vista; 7)

21

Video signal

VGA,DVI,RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION and so on.

22

MTBF

≥10000 hours

23

Longevity

≥100000 hours

24

Certification

UL/CE/CCC
