Specifications
> Clear,exquisite,real display effect> Big view angle
> Can repair each LED Lamps
> Low cost of repair
> No color excursion
LED Video Board's specifications:
number |
Item name |
Parameter and index |
unit module | ||
1 |
LED encapsulation mode |
SMD 3528 Surface mounted |
2 |
Horizontal axis |
160° |
3 |
Vertical axis |
160° |
4 |
Pixel composition |
1R1G1B |
5 |
Pixel pitch |
6mm |
6 |
Scan method |
1/8 Scan |
7 |
Drive method |
Constant current |
8 |
Module resolution |
32dots× 32dots |
9 |
Module dimensions |
192x192mm |
10 |
Module type |
Synergetic lamp and drive |
11 |
Module working voltage |
+5V |
12 |
Average Power Consumption |
6.25W |
13 |
Cabinet Maximum Power Consumption |
25W |
14 |
Module shell material |
PC |
15 |
Module mask material |
PC |
unit cabinet | ||
1 |
Module layout |
4×4 pieces |
2 |
Cabinet resolution |
128dots× 128dots |
3 |
Cabinet maximum power |
500W |
4 |
Cabinet average power |
125W |
5 |
Cabinet dimension |
768mm×768mm |
6 |
Cabinet material |
steel/aluminum alloy |
7 |
Cabinet color |
black/gray |
Entire screen | ||
1 |
Application environment |
indoor |
2 |
White balance brightness |
>1800cd/m2 |
3 |
White balance coordinates |
X=0.29,Y=0.31 |
4 |
contrast |
64000:1 |
5 |
Color temperature |
8000K |
6 |
Pixel density(pixels/m2) |
27777 |
7 |
Average consumption(W/m2) |
212Hz |
8 |
Maximum consumption(W/m2) |
848Hz |
9 |
Power source |
AC220V/50HZ or AC110V/60HZ |
10 |
Operating temperature |
-10°C~ +45°C |
11 |
Operating humidity |
10%~90% |
12 |
Storage humidity |
-30°C ~ +50°C |
13 |
Refresh frame rate |
60Hz |
14 |
Refresh rate |
480Hz |
15 |
Viewing distance |
6-100m |
16 |
grayscale/color |
16.7M |
17 |
Brightness adjustment |
100 manual levels /100 auto levels |
18 |
Control method |
synchronous with the computer display |
19 |
signal transfer distance |
Network cable:100m |
20 |
Computer operating system |
WINDOWS(98,2000,XP,Vista,7) |
21 |
Video signal |
VGA,DVI,RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION and so on. |
22 |
MTBF |
≥10000 hours |
23 |
Longevity |
≥100000 hours |
24 |
Certification |
UL/CE/CCC |
Case show:
Our factory shows:
