FTTH Indoor/Outdoor Drop Fiber Optic Cable
FTTH Drop Cable manufactured by ANC International Co., Limited is a kind of special curved optical fiber, which providing greater bandwidth and enhanced network transmission characteristics. This cable replaces the standard copper wire of the local Telco as it can carry high-speed broadband services integrating voice, data and video, and runs directly to the junction box at the home or building. ANC supplies FTTH Indoor Cable, FTTH Drop Cable, FTTH Duct Armored Cable, etc. In order to cut inventory costs and speed up the installation process for our customers, ANC’s FTTH cable designs can simplify your project.
Specification
250um fiber, easy to rip
Two High-Strength FRP cover
Small Size (mm): 3.1*2.0 (1-2cores indoor); 4.1*2.0 (4cores indoor); 5.3*2.0 (1-2cores outdoor); 6.1*2.0 (4cores outdoor)
Bending loss (Bare Fiber) Radius: 7.5mm x 1 turn dB ≤0.5 at 1550nm
Minimum bent radius: 15mm
Storage Temperature: -40~60°C
Features
The optical fiber meets the requirement of Etisalat specifications
Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber
Simple structure, lightweight and high practicability
Novel flute design, easily strip and splice, simplify the installation and maintenance
Low smoke, zero halogen or flame retardant sheath
Usage
FTTH system
Indoor riser level and plenum level cable distribution
Interconnect between instruments, communication equipment
Technical Data
Cable Count |
Out Sheath |
Weight |
Minimum Allowable Tensile Strength |
Minimum Allowable Crush Load |
Minimum Bending Radius |
Storage |
|||
|
(MM) |
(KG) |
Short term |
Long term |
Short term |
Long term |
Short term |
Long term |
(℃) |
1 |
(2.0±0.2)×(5.0±0.2) |
20 |
200 |
100 |
1000 |
300 |
20D |
10D |
-40+60 |
2 |
(2.0±0.2)×(5.0±0.2) |
20 |
200 |
100 |
1000 |
300 |
20D |
10D |
-40+60 |
3 |
(2.0±0.2)×(5.0±0.2) |
21 |
200 |
100 |
1000 |
300 |
20D |
10D |
-40+60 |
4 |
(2.0±0.2)×(5.0±0.2) |
22 |
200 |
100 |
1000 |
300 |
20D |
10D |
-40+60 |
1.Inquiry will be replied in 24hrs;
2.Sample charge: 1-2 pcs samples offered by free;
3.OEM&ODM are welcome;
With years of export experience along with excellent quality, advanced services and competitive prices,ADP has won numerous customers' trust and support.
