Self Supporting Telephone Wire in One Pair Parallel Conductor
Negotiable
MOQ: 30 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
shenzhenADP cables
Model Number:
Self Supporting Telephone Wire
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
shenzhenADP cables
Model Number
Self Supporting Telephone Wire
Shielded Cable
No
Conductor Material
CU,CCA,CCS
Jacket Color
black
Jacket Material
PVC or PE
Length
100m,200m,300m/ roll
Specifications
Self Supporting Telephone Wire in One Pair Parallel Conductor1,OEM service
2,fast delivery
3,best price
Self Supporting Telephone Wire in One Pair Parallel Conductor
APPLICATION(S):
-Self supporting drop wire one pair parallel conductor drop wire intended for aerial service
connection to the subscriber.
TEMPERATURE RATING:
-Storage and operation temperature range
-20 degree to 80 degree
-Installation temperature range
-10 degree to 60 degree
Core construction:
-Conductors
18AWG solid 30% conductivity extra high strength copper covered steel
-Sheath
Black, flame-weather PVC compound extruded over two conductors in a parallel configuration.
Electrical Characteristics:
Electrical Characteristics:
-DC Conductor Resistance: (max) Ohms/kft.@ 20 degree
Individual Conductor: 24.5
-Insulation Resistance (wet)
Megohms-kft.Mininum of 15.6 degree: 100
-Dielectric Strength: (Min)
(Wet) Vdc: 7050
(Dry) Vdc: 12100
-1 kHz Mutual Capacitance: (avg.)
(Wet) F-kft: 0.040
-Attenuation: (max)
dB-kft. @75 kHz: 4.0
Specification:
| 1.PHYSICAL DIMENSIONS | |||
| Diameter of Conductor,mm | 1.02mm +/-0.01 | ||
| Min. insulation Thickness.mm | 1.00mm | ||
| OVERALL DIAMETER | Major .MM | 6.3-7.50 | |
| Minor.MM | 3.15-4.5 | ||
| H.PHYSICAL TESTS | |||
| A.Conductor | |||
| Elongation, % | 1.5 | ||
| Tensile strength,kg/mm2 | 128 | ||
| B.Insulation | |||
| Elongation, % | 7.5 | ||
| Tensile strength,kg/mm2 | 0.0186 | ||
| ELECTRICAL TESTS | |||
| Conductor Resistance,ohm/KM | 80.4 | ||
Cable image:
