Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > Category3 UTP 24AWG 0.50mm Bare Copper 10 Pair Indoor Non Armored No Jelly PVC Sheath Telephone Cable
Category3 UTP 24AWG 0.50mm Bare Copper 10 Pair Indoor Non Armored No Jelly PVC Sheath Telephone Cable
Negotiable
MOQ: 2000 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ADP&OEM
Model Number:
HYAT
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Outdoor Underground Armored 120 Pair Telephone CableNegotiableMOQ: 5 Kilometers -
Outdoor Direct Burial 50/100/200/300 Pairs Cat3 Jelly Filled Telephone CableNegotiableMOQ: 1000 Kilometers
-
Big Pair 16 Pairs Telephone Cable,cat3 CablesUS$ 56 - 100MOQ: 100 Rolls
-
30 Pair Telephone CableNegotiableMOQ: 20 Kilometers
-
Outdoor Direct Burial 50/100/200/300 Pairs Cat3 Jelly Filled Armoured Telephone CableNegotiableMOQ: 1000 Kilometers
Place of Origin
Guangdong, China
Brand Name
ADP&OEM
Model Number
HYAT
Category3 UTP 24AWG 0.50mm Bare Copper 10 Pair Indoor Non
Armored No Jelly PVC Sheath Telephone Cable
HYA:Copper conductor jelly filled polyolefin insulation PE sheath city communcation cable
Product Description
Description:
1.standard: YD/T630-93
2, inner conductor:solid annealing bare copper, OD: 0.4 mm to 0.5 mm
3, insulation: HDPE
3, insulation: HDPE
4.sheath: aluminum-plastic composite PE
5.pairs:5/10/20/30/50/100/200/300 pairs are available
Applicaiton:
suitable for the local telecommunication network of cities and towns telecommunications lines, can also be applied to public network access to the private network lines. In aerial installation requires the use of messenger wire bearing. In - 30 °C ~ + 60 °C environment conditions, the mechanical and electrical properties of the cable remain unchanged.
Laying Method:
overhead or pipe laying, also can be directly buried.
Main electrical performance:
1. Dc resistance: 20 °C, 0.4 ≤148Ω/km 0.5 ≤95.0Ω/km 0.6 ≤65.8Ω/km 0.8 ≤36.6 Ω/km2.
2.The insulated electrical strength: 1 min 1 kv no breakdown between the conductor and conductor shielding 1 min 3 kv is not breakdown
3. The insulation resistance: each conductor and the rest of the grounding wire core, the charge cable is more than 10000 m Ω. Km, filling type cable is more than 3000 m Ω. Km.
4. Work capacity: average 52 plus or minus 2 nf/km
5. The far end crosstalk defense: 150 KHZ specified when the combination of the average power is greater than 69 db/km.
