92*25mm Waterproof Cooling Fan dc 5v 12v 24v
US$ 0.4 - 1.5
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
DC
Mounting:
Free Standing
Blade Material:
Plastic
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
120*25mm Waterproof Cabinet Cooling FanUS$ 0.55 - 1.5MOQ: 1000 Pieces -
120*38mm dc Ps3 Cooling FanUS$ 1.5 - 2.5MOQ: 1000 Pieces
-
Super High Power 40*28mm Waterproof dc FanUS$ 1 - 2MOQ: 1000 Pieces
-
50*15mm Waterproof Cooling Blower FanUS$ 0.5 - 1.5MOQ: 1000 Pieces
-
75*30mm Waterproof dc Fan AxialUS$ 1 - 2MOQ: 1000 Pieces
Electric Current Type
DC
Mounting
Free Standing
Blade Material
Plastic
Place of Origin
Guangdong, China
Brand Name
SON TIMES
Model Number
ST9225HS(B)
Voltage
12/24V/48V
Power
0.96-3.84W
Air Volume
45.16-57.47CFM
Speed
2000-3000RPM
Certification
CE
Specifications
1.waterproof cooling fan dc2.size:92*92*25mm
3.rated voltage:12/24/48v
4.ball bearing/sleeve
5.2000-3000PM,0.04-0.20A
| Frame size(mm) | 92*92*25mm | |
| Bearing type | ball bearing/sleeve | |
| Rated voltage | 12/24v/48v | |
| Rated speed | 1800-2200RPM | |
| Max air flow | 70-90CFM | |
| Max pressure | 0.14-0.20inch-H2O | |
| Max noise | 29-33dBA | |
| Functions | by impedance,FG | |
| Safety approvals | CE ROHS | |
| Dielectric Strength | 5mA max at 1500VAC for 1 min between lead wire and frame | |
| Insulation resistance | 100M ohm between lead wire and frame(DC 500V) | |
| Life expectancy(ball bearing) | 70000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |
| Life expectancy(hypro bearing) | >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20% | |
| Operation temperature | -10~80 degree C(+14~176 degree F) | |
| Storge temperature | -40~75 degree C(-40~167 degree F) | |
| Protection | Motor protection and polarity protection | |
| Lead wire | UL1571 AWG26,28; UL1007 AWG26,28; UL1061 AWG30 | |
| fan blade material | Black PBT (UL94V-0) glass filled | |
| frame material | PBT | |
| Weight | 78g |
