Excellent Quality Quality172*51mm Waterproof Fan 230v ac

Excellent Quality Quality172*51mm Waterproof Fan 230v ac thumbnail-1
Excellent Quality Quality172*51mm Waterproof Fan 230v ac photo-1
US$ 6 - 8 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Free Standing
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Son Times Electronics & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Mounting Free Standing
Blade Material Plastic
Place of Origin Guangdong, China
Brand Name son times
Model Number ST17251H2B
Voltage 110-380v
Power 40W
Air Volume 300CFM
Speed 3000RPM
Certification CE

Specifications

1.excellent quality fan ac 230v
2.size:172*150*51mm
3.ball bearing
4. large airflow,waterproof
5.Operating life:3years



                                    ST17251HBfan 230v ac excellent quality quality172*51mm waterproof fan 230v ac

Frame size(mm) 172X150X51mm
Bearing type ball bearing
Rated voltage 115V/50,60HZ, 230V/50,60HZ
Rated speed 2100~2700RPM
Max air flow 189CFM
Max pressure 10.36mmAq
Max noise 57dBA
Functions by impedance,FG
Safety approvals CE ROHS
Dielectric Strength 1000VAC for 1 minute to base on UL-507
Insulation resistance 100M ohm between lead wire and frame(DC 500V)
Life expectancy(ball bearing) 70000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
Life expectancy(hypro bearing) >40000hrs min at 40 degree C/L10 relative humidity 65%+/-20%
Operation temperature -10~80 degree C(+14~176 degree F)
Storge temperature -40~75 degree C(-40~167 degree F)
Protection Motor protection and polarity protection
Lead wire UL1430AWG22
Plastic material Black PBT (UL94V-0) glass filled
