Specifications
Perforated sintered mesh1.Filter Rating: 1-200micron
2.Width: Max:1200mm
3.Length: Max:1200mm
4.Material: SS304 316 316L
Perforated Sintered 304 316 316L Stainless Steel Mesh
Perforated Sintered Stainless Steel Mesh Laminate is made by several layers of woven wire mesh and sintered them to a layer of perforated metal. Due to the support of the perforated plate, sintered wire mesh laminate has a high resistance to pressure. Perforated sintered stainless steel mesh is suitable for a variety of applications, for example, in oil wells, where fine woven wire mesh layers need to filter under extremely high pressure condition.
Material for Perforated Sintered Stainless Steel Mesh:
standard materials are SUS304(AISI304), SUS316(AISI316), SUS316L(AISI316L), Titanium. Besides, special Alloy Steel Hastelloy, Monel, Inconel are available as per your requirement.
Dimension for Perforated Sintered Stainless Steel Mesh:
Standard size: 500x1000mm, 600x1200mm and 1000x1000mm, 1200x1200mm, besides, others within the above sizes are available according to your requirement.
Perforated Sintered Stainless Steel Mesh cross section structure:
|
| Type | Filter Rating u |
Structure | Thickness mm |
Weight kg/sqm |
Air Void % |
C4-2.0T |
2—200 |
30+filter layer+30+Diam4×5p×1.0T |
2.0 |
6.7 |
57 |
C4-2.5T |
2—200 |
30+filter layer+30+D5×7p×1.5T |
2.5 |
9.8 |
50 |
C5-3.0T |
2—200 |
60+filter layer+60++20+D6×8p×2.0T |
3.0 |
11.8 |
50 |
C5-3.5T |
2—200 |
20+filter layer+20+10+D8×10p×2.0T |
3.5 |
12.6 |
54 |
C5-4.0T |
2—200 |
20+filter layer+20+10+D8×10p×2.5T |
4.0 |
14.2 |
55 |
C5-4.3T |
5—200 |
20+filter layer+20+10+D10×13p×3.0T |
4.3 |
16.9 |
50 |
C5-5.3T |
5—200 |
20+filter layer+20+10+D10×13p×4.0T |
5.3 |
20.6 |
51 |
