Specifications
Conveyor Belt1. Wire diameter: 0.9 - 3.2 mm
2. Pitch: 4- 23mm
3. Belt width: 10 cm -3-metre
4. Aaperture ratio: 70%-85%
304 Stainless Steel Flat Flex Stainless Steel Conveyor Belt
Flat-flex stainless steel conveyor belt is designed to be C-shaped curved end loops, the pattern has advantages of not tangling during shipment, storage, or installation. Flat-flex conveyor belts have a light weight, single layer structure and positively driven by sprockets.
Aaperture ratio: 70% - 85%
Material: Flat-flex conveyor belts are made of stainless steel wire 304 316
Wire diameter: varies from 0.9 mm to 3.2 mm.
Pitch: from 4mm until 23mm
Belt width: from 10 cm until 3 metres.
We can make conveyor belt as per your requirement. Conveyor belts are finished with single loop commonly or double looped edges for special occasions.
Application: Flat-flex conveyor belt can be made for straight conveyors or for curved conveyors, frequently used in cooling, frying, baking, draying, heating, decorating, battering and packing machines for light products, especially usd in food industry such as, snacks, fish, pizzas, bread, pastry, candy, potato, biscuit, chocolate, nuts, fruit etc.
Flat-flex conveyor belt specification described from several aspects as below:
| Pitch(mm) | 7.26mm | 7.26mm | 6.00mm | 7.26mm | 12.7mm | 7.26mm | 7.26mm |
| Wire diameter(mm) | 1.57mm | 1.57mm | 1.27mm | 1.57mm | 2.34mm | 1.57mm | 1.27mm |
| No. of spaces | 3 | 5 | 7 | 7 | 7 | 7 | 9 |
| Overal width(mm) | 203mm | 356mm | 400mm | 457mm | 500mm | 560mm | 600mm |
