Specifications
304 SS Wire Belt1. Good quality
2. Competitive price
3. Manufacturer
4. ISO9001 & SGS certificated
Wire Belt Innovative Conveyor Belt
Wire Belt width is 150-5500mm, 304 Wire Belt work speed is 0.15-0.5m/min, the edge of 304 stainless steel wire belt can be curved, the wire belt 304, which is made by assembling the successfully bent wire.
The detailed information listed below:
1. The steel wire belt mesh width: 150-5500mm
2. With wire belt speed work: 0.15-0.50m/ min
3. The edge of the form: Curved edge, upsetting the first, in the form of welding
4. Material: Besides Stainless steel wire ( 304, 304 L, 302, 201, 316, 316 L, 2520, 2080), the wire belt can also be made from stainless iron wire, middle and low carbon steel wire, galvanized wire ( hot galvanized, electroplating), chromium iron wire, nickel chromium wire, aluminum wire, polyester wire etc.
Wire Belt Specification examples:
| Pitch(mm) | 7.26mm | 7.26mm | 6.00mm | 7.26mm | 12.7mm | 7.26mm | 7.26mm |
| Wire diameter(mm) | 1.57mm | 1.57mm | 1.27mm | 1.57mm | 2.34mm | 1.57mm | 1.27mm |
| No. of spaces | 3 | 5 | 7 | 7 | 7 | 7 | 9 |
| Overal width(mm) | 203mm | 356mm | 400mm | 457mm | 500mm | 560mm | 600mm |
Weaving method and characteristics:
The shape of organization structure including: Ordinary weaving, reinforced weave, part ordinary weaving, etc. Spiral Press Filter Belt is mainly used in sludge dewatering and desiccation, paper pulp washing, coal washing, chemicals, dehydration of wine bran, vinegar bran dehydration and other industries. It is better in the high ventilation part of the dryness part of paper-making machine.
Characteristics of Wire Belt Innovative Conveyor Belt:
1. With good corrosion resistance, wear-resistant, high temperature performance.
2. Moderate and high temperatures in the negative satisfaction with the anti-oxidation, anti-fracture performance.
3. Well-designed, compact, multi-standard, easy to install, reliable operation, and other advantages.
