Specifications
Wire Mesh Belt1. Wire diameter: 0.9 -3.2 mm
2. Pitch: 4-23mm
3. Belt width: 10 -3-metre
4. Aaperture ratio 70%-85%
Stainless Steel 304 Flat-flex Conveyor Belt/Wire Mesh Belt
Flat-flex conveyor belt is designed to be C-shaped curved end loops, the pattern has advantages of not tangling during shipment, storage, or installation. Flat-flex conveyor belts have a light weight, single layer structure and positively driven by sprockets.
Aaperture ratio: 70% - 85%
Material: Flat-flex conveyor belts are made of stainless steel wire 304 316
Wire diameter: varies from 0.9 mm to 3.2 mm.
Pitch: from 4 mm until 23mm
Belt width: from 10 cm until 3 metres.
We can make conveyor belt as per clients' requirement. Conveyor belts are finished with single loop commonly or double looped edges for special occasions.
Application: Flat-flex conveyor belt can be made for straight conveyors or for curved conveyors, frequently used in cooling, frying, baking, draying, heating, decorating, battering and packing machines for light products, especially usd in food industry such as, snacks, fish, pizzas, bread, pastry, candy, potato, biscuit, chocolate, nuts, fruit etc.
Flat-flex conveyor belt specification description as below:
| Pitch(mm) | 7.26mm | 7.26mm | 6.00mm | 7.26mm | 12.7mm | 7.26mm | 7.26mm |
| Wire diameter(mm) | 1.57mm | 1.57mm | 1.27mm | 1.57mm | 2.34mm | 1.57mm | 1.27mm |
| No. of spaces | 3 | 5 | 7 | 7 | 7 | 7 | 9 |
| Overal width(mm) | 203mm | 356mm | 400mm | 457mm | 500mm | 560mm | 600mm |
