304 stainless steel flat flex wire mesh conveyor belt

Specifications

Heat resistant
Environment protection
Food production system applied available
Min 1mm wire dia
working speed 0.15-0.50m/min

stainless steel conveyor belt structure diagram:

stainless steel conveyor belt specification description examples:

Pitch(mm)	7.26mm	7.26mm	6.00mm	7.26mm	12.7mm	7.26mm	7.26mm
Wire diameter(mm)	1.57mm	1.57mm	1.27mm	1.57mm	2.34mm	1.57mm	1.27mm
No. of spaces	3	5	7	7	7	7	9
Overal width(mm)	203mm	356mm	400mm	457mm	500mm	560mm	600mm

stainless steel conveyor belt application:
cooling systems; drying systems; food production systems; washing systems; sorting systems etc.
Characteristics of conveyor belt mesh:
1. The stainless steel conveyor belt width: 150-5500mm
2. Working speed: 0.15-0.50m/ min
3. The edge of the form: Curved edge, upsetting the first, in the form of welding
4. Material: stainless steel wire ( 304, 304 L, 302, 201, 316, 316 L, 2520, 2080), stainless iron wire, middle and low carbon steel wire, galvanized wire ( hot galvanized, electroplating), chromium iron wire, nickel chromium wire, aluminum wire, polyester wire etc.
