Specifications
Floating fish feed pellet machine1. Twin screw Extruder
2. Various Shapes to get by adjusting the mould from extruder
Floating fish feed pellet machine
1. Description:
Twin screw extruder is deliberately made for special feed, which needs high in-shape rate and good-looking appearance. It is mainly used for sinking/floating/slow sinking aqua feed and pet food. Effectively protect the aquaculture water body from pollution to improve the quality of life.
2. Raw materials: adopts corn flour, fish meal as raw materials
3. Products: This line can be used to produce fish pellets, the pellets size can be from 1.0mm to 9.0mm by adjusting the moulds from extruder; meanwhile it can produce dog food, cat food
4. Capacity: 150kg/h, 240kg/h, 500kg/h, 1ton---3ton/h
5. Flow chart:
Mixing system---Extrusion system----Drying system----Flavoring system--Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
7. Machines materials: All the machines are made by stainless steel, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
AMC65 |
70kw |
40kw |
100-150kg/h |
22000x1200x2200mm |
AMC70 |
90kw |
50kw |
200-240kg/h |
25000x1500x2200mm |
AMC85 |
120kw |
100kw |
400-500kg/h |
30000x3500x4300mm |
AMC90 |
135kw |
100kw |
800-1000kg/h |
30000x3500x4300mm |
AMC115 |
165kw |
115kw |
1000-2000kg/h |
30000x3500x4300mm |
9. Sample pictures
