Help CenterASTM B348 Grade 5 Titanium Bar for Medical
Related Products
Specifications
1,ASTM B348 Grade 5 Titanium Bar for Medical2.D:5.35~300 mm
3.Accuracy:H7,H8,H9
4.Original mill test report
Titanium Bars
High Precision
Grades:Ti6Al7Nb,Ti13Nb13Zr,Ti6242,Ti6246,NbTi
Standard:ASTM B348 ,F67,F136,F1713
H9,H8,H7
Titanium Bars
1 Grades:Gr1,Gr2,Gr3,Gr4,Gr5,Gr9,Gr12,Gr19,GR23,Ti6242,Ti6246,NbTi
2 Standard:ASTM B348 ,F67,F136,F1713 etc
3 High Precision:H9,H8,H7
Titanium Bars Features:
a) Type: titanium bars, rods sections & profiles
b)Standard: ASTM B348; AMS4928(Ti 6Al4V)
Medical Class: ASTM F136(Eli 6AL4V) ;ASTMF 67(Gr 2)
c)Sizes: custom sizes are available
d)Grades: Gr 1, Gr 2, Gr 3, Gr 4, Gr 5, Gr 7, Gr 9, Gr 12
e)Test: mechanical properties test
f)Applications: offshore, chemical processing, medical instruments,etcPacking:Box, crate, single board or burlap
| Grade | ELEMENT COMPOSITION,% | ||||||||
| Ti | Al | V | Fe | C | N | H | O | Other,Max | |
| Grade 1 | Blance | _ | _ | 0.20 | 0.8 | 0.03 | 0.015 | 0.18 | 0.40 |
| Grade 2 | Blance | _ | _ | 0.30 | 0.8 | 0.03 | 0.015 | 0.25 | 0.40 |
| Grade 3 | Blance | _ | _ | 0.30 | 0.8 | 0.05 | 0.015 | 0.35 | 0.40 |
| Grade 4 | Blance | _ | _ | 0.50 | 0.8 | 0.05 | 0.015 | 0.40 | 0.40 |
| Grade 5 | Blance | 5.5-6.75 | 3.5-4.5 | 0.40 | 0.8 | 0.05 | 0.015 | 0.50 | 0.40 |
| Grade 7 | Blance | _ | _ | 0.03 | 0.8 | 0.03 | 0.015 | 0.25 | 0.40 |
| Grade 9 | Blance | _ | _ | 0.25 | 0.8 | 0.03 | 0.015 | 0.15 | 0.40 |
| Grade 12 | Blance | _ | _ | 0.30 | 0.8 | 0.03 | 0.015 | 0.25 | 0.40 |
| Grade | Tensile Strength,min | Yield Strength,0.2% Offset | Elongation,min % | ||||
| Ksi | Mpa | min | max | ||||
| Ksi | Mpa | Ksi | Mpa | ||||
| Grade 1 | 35 | 240 | 20 | 138 | 45 | 310 | 24 |
| Grade 2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
| Grade 3 | 65 | 450 | 55 | 380 | 80 | 550 | 18 |
| Grade 4 | 80 | 550 | 70 | 483 | 95 | 655 | 15 |
| Grade 5 | 130 | 895 | 120 | 828 | _ | _ | 10 |
