Help CenterASTMB348 Polished Tc4 Titanium Alloy Bar
Related Products
Specifications
1.ASTMB348 Polished tc4 titanium alloy bar2.high grade titanium bar
3.Prompt delivery
4.Can be customized
high grade titanium bar
The density of titanium is 4.506-4.516g/cm^3, melting point is 1668, boiling point is 3535. In the appropriate oxidizing environment also has excellent corrosion resistance. Therefore, products are widely used in aerospace structural materials, such as aircraft, rockets, missiles and spacecraft, ship manufacture, chemical industry, conventional weapons, manufacturing, metallurgical industry, health care, ultra-high vacauum and other fields.
| Element | Composition,% | |||||||||
| Grade1 | Grade2 | Grade3 | Grade4 | Grade5 | Grade6 | Grade7 | Grade9 | Grade11 | Grade12 | |
| N max | 0.03 | 0.03 | 0.05 | 0.05 | 0.05 | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 |
| C max | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 |
| H max | 0.05 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 |
| Fe max | 0.2 | 0.3 | 0.3 | 0.5 | 0.4 | 0.3 | 0.5 | 0.25 | 0.2 | 0.3 |
| O max | 0.18 | 0.25 | 0.35 | 0.4 | 0.2 | 0.2 | 0.25 | 0.15 | 0.18 | 0.25 |
| Al | 5.5-6.75 | 4.0-4.6 | 2.5-3.5 | |||||||
| V | 3.5-4.5 | 2.0-3.0 | ||||||||
Our high quality products are manufactured according to ASTM, AMS and some other world-wide recognized accords.
| Titanium Bar/Titanium Rod We can Supply | |||||||
| Grade | Standards | Diameter(mm) | |||||
|
Gr1, Gr2, Gr3, Gr4, Gr5, Gr6, Gr7, Gr9,Gr12, Gr23 TI-6AL-7NBTI-13NB-13ZR |
GB/T 13810-2007 | 4-200 | |||||
| ASTM B348 | 2-120 | ||||||
| ASTM F136 | 2-100 | ||||||
| ISO5832-3/AMS | 2-100 | ||||||
1.AstmB348 Polished tc4 titanium alloy bar
1.size: OD:2-300mm
2.manufacturing:forged
3.standard:astm b381
4. supply condition:R&M
5.application: chemical industrial,medical,aerospace,oceaneering
2.Featrues
Product Name |
bar |
|
Available Sizes |
Diameter |
Length |
3-200mm |
100-5000mm |
|
Titanium Grade |
Grade 5 titanium unalloy |
|
Standard |
ASTMB348, ASTMF67,ASTMF136,AMS4928 |
|
Diameter Tolerance |
DIA 3-200mm |
DIA 3-200mm |
+/-0.05mm |
+/-0.1mm |
|
Surface Quality |
Polished |
|
Production Technology |
Rolled |
|
Supply Status |
Annealed |
|
3, Packaging & Delivery
packetail:commonly plastic bag as inside, wooden case as outside, or according to client's demand
