This hydraulic machine is suitable for pressure processing of plastic, metal and all kinds of matericals.
This machine is suitable for pressure processing of plastic matericals; it is used in fitting, bending, side bending and sheet metal drawing ect. It can be also used for correcting, pressing, grinding wheel modularizing, cold extrusion of metal parts, and plastic, sintered and insulating material compacting.
Stamping buffer device
moving table
oil heating & cooling device
stroke sensor
industrial touched screen
floating guide and rolling racket for die changing
die illuminating device
tool quick clamp device
slide locking device
proportional pressure & speed adjusting device for slide
light curtain
ejcting device(hudraulic or mechanical)
PLC imported PLC
Power socket
die changing dolly
manipulator
imported seal
die
top located hydraulic system
die protecting device
Serial Number |
Project |
Unit |
Standard |
||
1000T |
Remarks |
||||
1 |
Normal force |
kN |
10000 |
|
|
2 |
Maximum working pressure of liquid |
MPa |
25 |
|
|
3 |
Maximum stroke of sliding block |
mm |
1000 |
|
|
4 |
Hydraulic cushion force |
kn |
4000 |
|
|
5 |
Hydraulic cushion stroke |
mm |
350 |
|
|
4 |
Open height |
mm |
1600 |
|
|
5 |
Stroke speed of sliding block |
Quickly down |
mm/s |
150-200 |
|
Slowly down and suppress |
mm/s |
15-20 |
|
||
|
Return stroke
|
mm/s |
100 |
|
||
6 |
Active areas of workbench |
Right and left |
mm |
3000 |
|
Front and back |
mm |
2000 |
|
||
7 |
Motor power |
kW |
2*45 |
|
|
8 |
Machine weight |
Tons |
120 |
|
|
9. Choose of Primary Master Copies
Serial number |
Name |
Manufacturer |
Remarks |
1 |
Value block |
Typhon in Jining |
|
2 |
High-pressure pump |
High pressure in Qidong |
|
3 |
Electrical machine |
Constant force in Nantong |
|
4 |
Main electric |
213 in Tianshui |
|
10 Acceptance Standards
10.1 Accuracy: According to GB9166-1999 Accuracy of Four-Column Hydraulic Press
10.2 Design and manufacture should conform to the
JB3818-1999 Technical Conditions of Hydraulic Press
JB3915-1985 Safety Specification of Hydraulic Machine
JB/T8609-1997 Welding Technical Conditions of Metal Forming Machinery
JB9967-1999 Noise Limitation of Hydraulic Press
GB/T5226.1-1996 General Technical Specification of Industrial Machinery Electrical Equipment
11. Technical Data
11.1 The following clear, integrated and correct documents are provided with the leave factory of machine: an operation instruction of equipment, which contents include the purposes and features of machine, main technical parameters, structure overview, hydraulic system, electric system, installation & debugging, maintaining, safe operation rules, etc. literal statements.
11.2 The following clear, integrated and correct drawings are provided with the leave factory of machine: general assembly drawing of equipment, principle diagram of hydraulic system, electrical schematic diagram, and ground plot of arrangement, etc. related drawings.
11.3 A qualified specification of equipment
11.4 A list of encasement
11.5 Several random replacement parts of seal rings, special tools, and foundation bolt.
