Ceramic Emitter (RE926-C)

Resucerial Quartz Lianyungang Industrial & Trading Co., Ltd.
Ceramic Emitter (RE926-C) thumbnail-1
Ceramic Emitter (RE926-C) photo-1
US$ 3 - 30 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Resucerial
Model Number:
RE926-C
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Resucerial
Model Number RE926-C
Type Ceramic Heater
Application Heater Parts
Certification CE

Specifications

five size: 122 x 62 x 25mm, 122 x 120 x 25mm, 248 x 62 x 25mm, 248 x 120 x 25mm,306 x 306 x 25mm
fast response, Rapid heat-up

Ceramic infrared heaters are 96% infrared energy efficient. Uses for electric infrared heat can be found in many industries and applications and can be grouped into four major categories: 1) Curing 2) Drying 3) Heating 4) Cooking 5) Saunas



Top right have has a wide range of IR ceramic heaters in ceramic and Quartz. Available With thermocouple & without thermocouple from 60 watts to 1000 watts.



Electric ceramic heater emitter Feature:

1. Durable, splash-proof, non-corrosive finish

2. Watt densities from 3 w/cm² (tolerance within +/- 2%)

3. Maximum temperature output is 1292 F (700 C.)

4. Available color in white/ black/yellow

5. Standard voltages: 220/230v (other volts available on request)

6. Estimated life in excess of 10,000 hours

7. Available With thermocouple & without thermocouple



Application:

The  ceramic heaters are widely used in pre-heating of plastic sheets for vacuum forming & thermoforming, drying paints, lacquer & varnish curing, drying printing inks, drying textiles, activating adhesives, removing surface water from objects or moisture removal from fabric and paper, animal husbandry and rearing. The ceramic IR heaters are highly efficient. Ceramic infrared heater offers precise targeting and control with minimal peripheral heat. It is possible to apply heat only where and when it is required. The energy in an infrared heater is transmitted at the speed of light from the element to the product. A constant rate of heating is obtained because the source temperature is normally much higher than that of the product even at the end of the heating cycle.





ceramic emitterRE926-C
 Parameter of ceramic emitter
ModelRE926-C
BrandResucerial
Applications
Plastic thermoforming,Blowing of plastic bottles, chemical industry, light industry, electronics, medicine, food



Radiation Wavelengths1-25um
CertificateCE
Life Time1500h
Heating Resistance WireNi-Cr-Al Alloy wire
Materialquartz sand
Shapeflat,curved
Colorwhite/black/yellow
Voltage12v,24v,36v,75v,110v,120v,220v,230v,240v,380v,400v,415v
Watts100-2000w
Sizes(Mm)245x65,240x60,120x60,120x120,248x80mm,248x90mm
Power Dflexural Strengthensity440kg/cm2
Insulation Resistance>100megohm
 Emissivity0.9
Largest Surface Load  5w/cm2







Size(mm)

Shape

Power( KW )

Size(mm)

Shape

Power(KW)

245×65

arc

0.25-1.0

300×300×16

flat

0.8-1.5

240×60

arc

0.5-1.0

240×160×16

flat

0.6-1.0

125×65

arc

0.2-0.5

Φ70

disk

0.1-0.2

120×60

flat

0.1-0.325

Φ100

disk

0.2-0.3

120×60

arc

0.1-0.325

Φ140

disk

0.3-0.4

120×120

flat

0.1-0.8

Φ150×Φ100×Φ60

half

0.25-0.3

120×120

arc

0.1-0.8

125×125

flat

0.4-0.8
